Product Details

EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine is perfect in every detail.EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine is commonly praised in the market due to good materials, fine workmanship, reliable quality, and favorable price.

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine runs the business in good faith and strives to provide professional services for customers.

Company Advantages
1. EcoPura water filling is manufactured using the latest machinery and known for its reliable attributes.
2. The product is anti-fading. Even exposed to the sunlight for several months in the hot summer, it can retain its luster and glossy.
3. The product will always provide the required consistency. It is programmed for repetitive and precise motion, so making mistakes is not easy.
4. The use of this product helps the producer in many ways which tend to increase his or her production and income.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

affordable bottle filler filling manufacturer for beverages-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3	0.33L-1.5L Height:150-330mm Dia: 50-115mm	2000-3000bph	1.5kw	SIEMENS
HSG16-12-6		3000-4500bph	1.8kw
HSG24-16-6		5000-6000bph	2.2kw
HSG24-18-8		7000-8000bph	2.2kw
HSG24-24-8		10000-12000bph	3.0kw
HSG32-32-12		15000-18000bph	5.5kw
HSG38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

affordable bottle filler filling manufacturer for beverages-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

affordable bottle filler filling manufacturer for beverages-3

affordable bottle filler filling manufacturer for beverages-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

affordable bottle filler filling manufacturer for beverages-5

affordable bottle filler filling manufacturer for beverages-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd began by making bottle filler and quickly became one of the largest producers in China.
2. Processed from the advanced machines, our automatic liquid filling machine enjoy a good reputation across the world.
3. The corporate culture EcoPura runs after is important for the development of EcoPura. Inquire online! Pursuit of excellence both in service and small liquid filling machine quality will be EcoPura's unceasing goal. Inquire online!

Carbonated Beverage Filling Machine, 3-In-1 Soft Drink Filling Machine

Soda Drink Washing Filling Capping Machine

1. This filling machine has washer, filler, and capper three functions in one body;

2. it is automatic in total process, suitable for PET bottled juice, mineral water, pure water and many other no gas containing drinks.

3. It makes by high quality SUS304, key parts are precision machined by NC tool.

4. The total machine uses advanced photoelectric detection technology to detect each parts operation status, no bottle no filling, and no bottle no capping, automatic & easy operation.

Model:	DCGF18-18-6	DCGF24-24-8	DCGF32-32-8	DGF40-40-10
capacity :500ml bottle per hour	3000 to 5000	6000 to 7000	8000 to 10000	10000 to 12000
bottle shape:	roud or square
PET bottle: (mm)	(Bottle Diameter):φ50-.φ110mm (Height):150-340mm
cap:	PE srew cap
filling precision:	≤±5mm
filling pressure:(Mpa)	0.15-0.35	0.15-0.35	0.15-0.35	0.15-0.35
rinsing pressure:(Mpa)	0.2-0.25	0.2-0.25	0.2-0.25	0.2-0.25
filling volume :(L)	3.5	4	6	8
overall size:(mm)	24501800 2350	27802200 2350	36002650 2350	38002950 2400
weight: (kg)	3500	4500	5500	6500

3in1 washing bottle machine(before filling soft drink)

3in1 Filling Soft Drink Machine(After Washing Bottle)

3in1 capping machine(after filling soft drink)

Full automatic sleeving and steam shrink label machine

Steam generator

Full automatic PE film packaging machine

Tell me your bottle volume and one hour filling capacity, right machine will be recommended to you.

As 500ml bottle is 6000 bottle per hour, or other capacity.

Why Mic Machinery

Model/Parameter

MIC-12/1

MIC-18/1

MIC-18/6

MIC-24/6

MIC-32/8

Application

Carbonated Drinks or Non-Carbonated Drinks for Aluminum Can and Tin Can

Capacity

2000CPH(330ML)

2000CPH(1L)

3000-6000CPH

4000-8000CPH

10000CPH

Feature

Count Pressure Filling, Low TPO, Less Foam, Stable Pressure, 99.5% Precision, Seaming Perfection
