Company Advantages1. To improve user experience, EcoPura tea filling machine is created with a compact and sleek design. Instead of adopting a thick and weighty design, it comes with a slim appearance.
2. The product is corrosion resistant. Its metal parts have been treated with surface paint to guard against oxidization and rust.
3. The product is not easy to break or crack. People can even put it in the dishwasher without the worry that the dishwasher would break it up.
4. With this product, people can leave their daily life behind and be whisked away to a place of imagination and fun!
ECOPURA 4-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles
Model | Bottle Spec | Capacity Cal@500ML | Power | PLC & HMI |
RHSG24-24-16-6 | 0.33L-1.5L
Height:150-330mm
Dia: 50-115mm | 5000-6000bph | 2.2kw | SIEMENS |
RHSG24-24-18-8 | 7000-8000bph | 2.2kw |
RHSG24-24-24-8 | 10000-12000bph | 2.0kw |
RHSG32-32-32-12 | 15000-18000bph | 5.5kw |
RHSG38-38-38-14 | 18000-20000bph | 7.5kw |
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us. |
Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard
High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components
The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.
Ozonated Water Washing Part
The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.
Filling Part
Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.
Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product
Perfect flow characteristics through two filling speeds
Cleaning in a closed system using automatically positioned CIP cups
Capping Part
The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish.As soon as the
rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process.
All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature
Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing
