Product Information
Feedback

Application Scope

water treatment equipment developed and produced by EcoPura Water Treatment Equipment & Bottling Machine is mainly applied to the following aspects.EcoPura Water Treatment Equipment & Bottling Machine always adheres to the service concept to meet customers' needs. We are committed to providing customers with one-stop solutions that are timely, efficient and economical.

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine carefully selects quality raw materials. Production cost and product quality will be strictly controlled. This enables us to produce water treatment equipment which is more competitive than other products in the industry. It has advantages in internal performance, price, and quality.Compared with similar products, EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment has the following advantages.

Company Advantages
1. EcoPura juice bottling machine is known for its style, selection, and value. .
2. This product meets the requirements of safe use. Safety testing has been performed based on mechanical design/performance, the intent of the product, the conditions of use and more.
3. It has a fine hardness. It has good cracking proof capacity and is not easy to deform due to the cold stamping process during production.
4. This product helps save production costs. There are potential savings to be gained from reduced medical claims of employees, greater production output.
5. The product is cost-saving. The use of this product can cut labor expenditure, which eventually brings more profits to manufacturers.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

standard juice bottling machine 3in1 more buying choices for upgrade industries-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

standard juice bottling machine 3in1 more buying choices for upgrade industries-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

standard juice bottling machine 3in1 more buying choices for upgrade industries-3

standard juice bottling machine 3in1 more buying choices for upgrade industries-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

standard juice bottling machine 3in1 more buying choices for upgrade industries-5

standard juice bottling machine 3in1 more buying choices for upgrade industries-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. As a top supplier of high quality, Shenzhen EcoPura Water Equipment Co.,Ltd is internationally renowned.
2. Our company has a high-efficient project management team. They are equipped with the required communication skills and decision-making ability to efficiently manage our order process.
3. We are committed to service excellence. We will strive to thoroughly understand and fulfill customer expectations, including 100% on-time delivery and the shipment of defect-free products. We aim to be a reliable and helpful partner that exceeds expectations and to manufacture products that meet the quality expectations of our clients all over the world. We are committed to meet or exceed the requirements of all applicable environmental, health, and safety legislation. So we set environmental objectives and targets each year based on the previous year’s results and trends, and spare no effort to achieve these targets. We aim to deliver high-quality products and responsive services for our existing and potential customers, helping them achieve constant profitable growth.

q******i

The design of EcoPura juice bottling machine involves several factors. These factors include part tolerances, size limitations, materials selection, mechanical analysis, function realization, etc. It has got CE approval and other many certifications

w******p

The workmanship of EcoPura juice bottle filling machine requires particular skills of machinists. It has to be welded, stamped, and brazed by professional workers, and its parts are put together and fastened by hands during assembly. It has low-friction ball bearings, ensuring the efficient work of the product

y******y

EcoPura juice bottle filling machine is manufactured in line with industrial standards. Its plug, electric cords, and socket are made complying with the local electricity supply system. With a simple structure, it only requires easy installation and maintenance

s******p

EcoPura juice bottle filling machine is manufactured by taking an array of regulatory compliance into considerations, including electrical safety, electromagnetic compatibility (EMC) and the chemical composition of materials. It is available in different colors like yellow and blue

g******x

EcoPura juice bottle filling machine meets electrical international standards. They generally include IEC 60038 (IEC standard voltages) and IEC60076 (Power transformers). It has an excellent nonlinearity correction function

h******y

This product has certain air permeability. It provides a tunnel for the skin to exchange air with the outside world. In the meantime, it contributes to the divergence of human heat. This product has certain air permeability. It provides a tunnel for the skin to exchange air with the outside world. In the meantime, it contributes to the divergence of human heat. It won't be affected by any factors like high temperature, pressure, density, viscosity, etc
