ECOPURA 5gallon bottle washing filling capping machine HSG600 with capacity 600bph.
A real Hygiene filling solution for your recycling use 5Gallon bottled water business with SIEMENS PLC Control and touch Screen control. All parts that come to contact with water are manufactured in Stainless steel 304 or 316L ,Equipped S.S304 Chemical tank for multistage rinsing

most popular water filling equipment water more buying choices for distribution-1

most popular water filling equipment water more buying choices for distribution-2

Bottles Sterilizing & Washing
Exclude the brusher pre-washing process for cleaning bottles inside & outside part, the pre-washed 5gallon bottles feed into the 3-in-1 washing filling capping unit which Designed Multistage high-pressure inner washing Process include Hot Alkaline washing, disinfection water washing, Dripping ,Ozonated pure water cleaning for ensuring the recycled bottles 100% clean & health, the washing system is controlled by pumping though cleaning tank and the ejecting nozzles on the bottle carrier to spraying the inner wall of the bottles by high pressure water, after finishing the washing process, the bottles will discharge though reverse turn-over mechanize and transported to the filling Part for full filling as designated volume and finally capping, discharge out the 3-in-1 by conveyor to next step
Caps Loading & washing

The Caps elevator doses the caps into the caps unscrambler then delivery through caps chute to enter into caps washing tunnel, finished clean caps feed following the chute transferring to capping position on capping machine .Design for online 5Gallon caps cleaning & Sterilizing by multistage washing process -detergent washing & purified water washing,

most popular water filling equipment water more buying choices for distribution-3

most popular water filling equipment water more buying choices for distribution-4

Rotary Filling & Capping

Clean bottles are discharged out of the rinse by conveyor to feed the filler. After entering the filler, bottles are retained by bottom supporting plates, which are actuated by bottle supporting mechanism to raise them to engage with filling valves. Filling valves are opened by bottle presence signals. After finishing filling, valves are closed by valve closing mechanism to further stop venting to complete the filling process.

Product Solution

A turnkey solution for 5Gallon bottling line

  • ♦ 1.Automatic bottle decapper

  •  2.Automatic inside & outside brusher washer

  •  3.Automatic bottle feeder -Multistage high-pressure washing unit

  •  4.Linear or Rotary filler & capper

  • ♦ 5.Automatic Capsules Labeling shrinking

  •  6.Light Inspection

  •  7.Thin film (bag) Packing

  • ♦ 8.Palletizer


In the production of EcoPura water filling machine for sale, we adopt lean production method. The product provides a fast response time
The stylish EcoPura water filling machine for sale is designed by our design experts. It is equipped with a digital transfer device, ensuring a fast transmission speed
EcoPura water filling equipment is manufactured employing the optimum quality raw material as per set industry guidelines. With a smart structure design, no debris will be left in it
EcoPura water filling machine for sale is delicately manufactured by excellent production team using advanced technology and sophisticated equipment. It has an excellent nonlinearity correction function
EcoPura water filling equipment is made by our skillful and experienced professionals. It is widely used in the chemical industry, metal & mining industry, etc
[企业简称] keeps up with the development trend of the industry, and adopts new technology and new technology to produce water filling machine for sale. The manufactured water filling machine for sale has excellent performance, stable quality, and reliable quality. It sells well in domestic and foreign markets and has won unanimous praise from customers.
