Product Information
Feedback

Product Details

EcoPura Water Treatment Equipment & Bottling Machine adheres to the principle of 'details determine success or failure' and pays great attention to the details of bottling line.EcoPura Water Treatment Equipment & Bottling Machine's bottling line is manufactured in strict accordance with relevant national standards. Every detail matters in the production. Strict cost control promotes the production of high-quality and priced-low product. Such a product is up to customers' needs for a highly cost-effective product.

Company Advantages
1. EcoPura mineral water filter machine price is engineered with the assistance of computers and various software. They are Computer-Aided Manufacturing (CAM) which includes CNC tool path and rapid prototyping as well as Engineering analysis and simulation which include finite element, fluid flow, dynamic analysis, and motion.
2. The product is characterized by high performance and good durability.
3. This product offers a versatile function and user-friendly operation.
4. The product caters to the development of industry market with broad prospects.

Product Detail

ECOPURA 5gallon bottle washing filling capping machine HSG1500 with capacity 1500bph
A real Hygiene filling solution for your recycling use 5Gallon bottled water business with SIEMENS PLC Control and touch Screen control. All parts that come to contact with water are manufactured in Stainless steel 304 or 316L ,Equipped S.S304 Chemical tank for multistage rinsing

most popular filling equipment 1200bph factory for distribution-1

most popular filling equipment 1200bph factory for distribution-2

most popular filling equipment 1200bph factory for distribution-3

most popular filling equipment 1200bph factory for distribution-4

most popular filling equipment 1200bph factory for distribution-5

Bottles Sterilizing & Washing

Exclude the brusher pre-washing process for cleaning bottles inside & outside part, the pre-washed 5gallon bottles feed into the 3-in-1 washing filling capping unit which Designed Multistage high-pressure inner washing Process include Hot Alkaline washing, disinfection water washing, Dripping ,Ozonated pure water cleaning for ensuring the recycled bottles 100% clean & health, the washing system is controlled by pumping though cleaning tank and the ejecting nozzles on the bottle carrier to spraying the inner wall of the bottles by high pressure water, after finishing the washing process, the bottles will discharge though reverse turn-over mechanize and transported to the filling Part for full filling as designated volume and finally capping, discharge out the 3-in-1 by conveyor to next step

Caps Loading & washing

The Caps elevator doses the caps into the caps unscrambler then delivery through caps chute to enter into caps washing tunnel, finished clean caps feed following the chute transferring to capping position on capping machine

Design for online 5Gallon caps cleaning & Sterilizing by multistage washing process -detergent washing & purified water washing

most popular filling equipment 1200bph factory for distribution-6

most popular filling equipment 1200bph factory for distribution-7

Rotary Filling & Capping

Clean bottles are discharged out of the rinse by conveyor to feed the filler. After entering the filler, bottles are retained by bottom supporting plates, which are actuated by bottle supporting mechanism to raise them to engage with filling valves. Filling valves are opened by bottle presence signals. After finishing filling, valves are closed by valve closing mechanism to further stop venting to complete the filling process.

Product Solution

A turnkey solution for 5Gallon bottling line

♦ 1.Automatic bottle decapper
♦ 2.Automatic inside & outside brusher washer
♦ 3.Automatic bottle feeder -Multistage high-pressure washing unit
♦ 4.Linear or Rotary filler & capper
♦ 5.Automatic Capsules Labeling shrinking
♦ 6.Light Inspection
♦ 7.Thin film (bag) Packing
♦ 8.Palletizer

Company Features
1. By integrating mineral water filter machine price and mineral water bottling plant , EcoPura has enough confidence to offer filling equipment with high quality and affordable price.
2. We have lean and flexible management layers. They are able to drive quick and effective decision making and thus enable the company to bring high-quality products quickly to market.
3. Shenzhen EcoPura Water Equipment Co.,Ltd has great ambitions to acquire the primary marketplace of mineral water bottle filling machine . Customers will definitely find something interesting at EcoPura Water Treatment Equipment & Bottling Machine. Contact! The excellent quality and professional service of Shenzhen EcoPura Water Equipment Co.,Ltd will satisfy you. Contact!

Product Description

Filling Machine Manufacturing Company And Dry Powder Filling Machine For Extinguisher

Description
SNAV Automatic Viscosity Filling Machine is applied for filling glue, liquid soap, shampoo and cream etc. In the industry of pharmaceutical and chemical. It completed and stable for filling heavy liquid and viscosity in the market place.

Characteristic
-Adopt volumetric piston pump with SS316 contact parts, pneumatic piston driving, application various kinds of material.
-Volume piston pump measure accurate filling volume, and easy to adjust volume.
-Top liquid hopper, auto supply stuff by level sensor.
-Auto shut on/off filling nozzles, with no leakage while filling.
-Convenient to clean and disinfect, no-tool to change other bottle size.
-Frequency conversion speed control, no bottle no fill.
-All electric elements adopt Mitsubishi, Schneider famous brand.
-Whole machine designed and manufactured accordance to GMP regulation.

Main Technical Parameter

Items	SNAV-4	SNAV-6	SNAV-8	SNAV-12	SNAV-16
Filling nozzles	4	6	8	12	16
Filling range	20-5000ml		20-500ml
Ideal filling range	20-100ml/50-250ml/100-500ml/200-1000ml/500-2500ml/1000-5000ml
Filling speed(100ml)bpm	30-40	40-60	60-70	70-100	90-120
Filling precision	20-1000ml: ≤±1% 1000-5000ml:≤±0.5%
Air pressure range	0.4-0.6Mpa
Power supply	220V 50/60HZ
Air consumption	10m3/h	15m3/h	20m3/h	30m3/h	40m3/h
Power consumption	0.75Kw	0.75Kw	1.2Kw	2.2Kw	2.2Kw
Single machine noise	≤50dB
Net weight	500kg	900kg	1150kg	1500kg	1750kg
Overall dimension(mm)	1300 x 1200 x 1800	1600 x 1200 x 1800	1900 x 1200 x 1800	2300 x 1200 x 1800	2600 x 1200 x 1800

Machine Photos

Our Services

After-Sale Service

1. We will send our technical enginner to your country to do installation, and training.

2. After our machine arrived to your country, we can send our technician to do the installation and training, and your part bear the airplane fee, the local accommadation and time fee.

3. One year free spare part free with our machine.
4. One year warranty.
Welcome to choice our product , please give us more advices . Thank you!

p******s

Shenzhen EcoPura Water Equipment Co.,Ltd The pursuit of excellence, adhere to the use of advanced concepts, high-quality materials and exquisite craftsmanship mineral water filter machine price, effectively guarantee the rationality of the structure mineral water filter machine price and the stability of performance, the quality is trustworthy.

n******h

Shenzhen EcoPura Water Equipment Co.,Ltd has modern workshops and equipment, and has multiple sets of imported inspection and testing devices, and the production personnel strictly follow the national quality management system during production mineral water bottle filling machine to ensure that mineral water bottle filling machine provided to customers is of excellent quality , high quality products.

u******c

Shenzhen EcoPura Water Equipment Co.,Ltd has a quality inspection team composed of professionals who specialize in testing the quality and quality of mineral water filter machine price to ensure that mineral water filter machine price is of high quality and excellent quality.

g******e

Shenzhen EcoPura Water Equipment Co.,Ltd There are large-scale workshops, standardized production workshops, modern production lines, and skilled technology and craftsmanship. The mineral water bottle filling machine produced is not only good in quality and excellent in quality, but also meets relevant international quality standards. The pass rate of products is high, and customers can rest assured Partner with us for purchasing.

w******g

Shenzhen EcoPura Water Equipment Co.,Ltd Always put product quality first, not only select high-quality raw materials and use advanced production technology to manufacture filling equipment, but also set up a professional quality inspection team to strictly monitor each production link and each production process, To ensure that the filling equipment produced are of high quality.

w******v

mineral water filter machine price have a great future in this realm because of its mineral water filter machine price. It can be used for a broad variety of liquids, such as oil, water, and chemical
