low moq wine bottling equipment wine factory for distribution

Low moq wine bottling equipment wine factory for distribution

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Product Information of low moq wine bottling equipment wine factory for distribution
Product Comparison
Well-chosen in material, fine in workmanship, excellent in quality and favorable in price, EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine is highly competitive in the domestic and foreign markets.Compared with products in the same category,EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine's outstanding advantages are as follows.
  • v s
Enterprise Strength
  • EcoPura Water Treatment Equipment & Bottling Machine provides practical and solution-oriented services based on customer demand.
Company Advantages
1. When producing EcoPura wine filler , our personnel makes use of advanced production techniques.
2. wine bottling equipment can be applied into wine filler .
3. The product is engineered to have very specific qualities such as flexibility, elasticity, resilience, and insulation, making it ideal for various industrial applications.
Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine


low moq wine bottling equipment wine factory for distribution-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG8-8-3G

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

5000-3000bph

1.5kw

SIEMENS

HSG16-12-6G

3000-4500bph

1.8kw

HSG24-16-6G

5000-6000bph

2.2kw

HSG24-18-8G

7000-8000bph

2.2kw

HSG24-24-8G

10000-12000bph

3.0kw

HSG32-32-12G

15000-18000bph

5.5kw

HSG38-38-14G

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

low moq wine bottling equipment wine factory for distribution-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

low moq wine bottling equipment wine factory for distribution-3

low moq wine bottling equipment wine factory for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part
After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

low moq wine bottling equipment wine factory for distribution-5

low moq wine bottling equipment wine factory for distribution-6

Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is one of Chinese most popular enterprises which manufactures and exports wine bottling equipment.
2. It is widely accepted that giving play to technological strength conduces to the reputation of EcoPura.
3. Shenzhen EcoPura Water Equipment Co.,Ltd can provide the best choice according to your needs. Ask! In today’s global competition, EcoPura's vision is to be a famous brand all over the world as a wine filling machine manufacturing. Ask! In this booming society, EcoPura aims to be a much better company in the area of wine bottling machine . Ask!
