low cost bottle filler water trade partner for beverages

Low cost bottle filler water trade partner for beverages

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Product Information of low cost bottle filler water trade partner for beverages
Application Scope
EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment is widely used in various scenes.EcoPura Water Treatment Equipment & Bottling Machine insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.
Enterprise Strength
  • With a focus on customers, EcoPura Water Treatment Equipment & Bottling Machine strives to meet their needs and provide one-stop professional and quality services wholeheartedly.
Company Advantages
1. EcoPura liquid filling machine is dealt with advanced technology.
2. The product has a robust industrial strength frame. It mainly runs forged materials such as hot-rolled steel and stainless steel and has better impact resistance.
3. The product can work flawlessly. It has a precise and advanced control system, which allows it to operate with high accuracy under the given instructions.
4. Because the product can greatly increase productivity, it can increase the flexibility of the manufacturer by adding and reducing contractors.
Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc


low cost bottle filler water trade partner for beverages-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG24-24-16-6

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

5000-6000bph

2.2kw

SIEMENS

HSG24-24-18-8

7000-8000bph

2.2kw

HSG24-24-24-8

10000-12000bph

3.0kw

HSG32-32-32-12

15000-18000bph

5.5kw

HSG38-38-38-14

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

low cost bottle filler water trade partner for beverages-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

low cost bottle filler water trade partner for beverages-3

low cost bottle filler water trade partner for beverages-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part
Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

low cost bottle filler water trade partner for beverages-5

low cost bottle filler water trade partner for beverages-6

Capping Part
The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature
Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

low cost bottle filler water trade partner for beverages-7


Company Features
1. Since its establishment, EcoPura brand has gained much more popularity.
2. The production process of bottle filler is advanced.
3. The goal of Shenzhen EcoPura Water Equipment Co.,Ltd is to bolster the technical advantage and become an specialist in the area of small liquid filling machine. Inquire! Shenzhen EcoPura Water Equipment Co.,Ltd is market-oriented and strives to comply with global standards. Inquire! Shenzhen EcoPura Water Equipment Co.,Ltd holds the firm belief that the quality stands above everything. Inquire!
Packaging 2

Accoring with export packaging standards:

  • The machine whole covered by PVC film & fumigated wooden case;

  • Wooden case suitable for long distance ocean shipping.
