Company Advantages1. The EcoPura automatic liquid filling machine is analyzed in depth in the original design.
2. The product maintains its flexibility at low temperatures. Due to its amorphous molecular structure, the low temperature has little effect on its properties.
3. This product contains no hazardous materials such as lead, cadmium, and mercury that can contaminate ground soil and water source.
4. Shenzhen EcoPura Water Equipment Co.,Ltd's sales performance has been steadily increasing these years.
5. Shenzhen EcoPura Water Equipment Co.,Ltd always provides the highest customer satisfied automatic liquid filling machine products.
ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

Model | Bottle Spec | Capacity Cal@500ML | Power | PLC & HMI |
HSG8-8-3 | 0.33L-1.5L Height:150-330mm Dia: 50-115mm | 2000-3000bph | 1.5kw | SIEMENS |
HSG16-12-6 | 3000-4500bph |
1.8kw |
HSG24-16-6 | 5000-6000bph |
2.2kw |
HSG24-18-8 | 7000-8000bph |
2.2kw |
HSG24-24-8 | 10000-12000bph | 3.0kw |
HSG32-32-12 | 15000-18000bph | 5.5kw |
HSG38-38-14 | 18000-20000bph | 7.5kw |
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us. |
High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components
The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.
Filling Part
Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP
Capping Part
The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height
Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature
Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing
Company Features1. With years of stable development, Shenzhen EcoPura Water Equipment Co.,Ltd has formed its own brand in global market.
2. Our factory has invested a lot of advanced facilities which are imported from overseas. They embrace a broad range of advantages, including the guarantee of high production, low energy consumption, and zero malfunction.
3. We are committed to service excellence. We will strive to thoroughly understand and fulfill customer expectations, including 100% on-time delivery and the shipment of defect-free products. We bear social responsibility. We are dedicated to protecting our precious environment and reducing the impact of our activities and those of our customers.
