low cost automatic liquid filling machine 4in1 factory for beverages

Low cost automatic liquid filling machine 4in1 factory for beverages

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Product Information of low cost automatic liquid filling machine 4in1 factory for beverages
Enterprise Strength
  • EcoPura Water Treatment Equipment & Bottling Machine has built a service system that meets the needs of consumers. It has won wide acclaim and support from customers.
Company Advantages
1. In manufacturing EcoPura water filling , state-of-the-art environmental technology is adopted. A unique combination of innovative technology is used for the purification of waste gas.
2. To ensure the quality, it will be fully tested by our professional staff.
3. The quality of the product is assured in every step of production.
4. This EcoPura branded product will find a ready market overseas.
5. The product uses its own strength to win the trust of many customers both at home and abroad and enjoys an increasing market share.
Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc


low cost automatic liquid filling machine 4in1 factory for beverages-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG8-8-3

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

2000-3000bph

1.5kw

SIEMENS

HSG16-12-6

3000-4500bph

1.8kw

HSG24-16-6

5000-6000bph

2.2kw

HSG24-18-8

7000-8000bph

2.2kw

HSG24-24-8

10000-12000bph

3.0kw

HSG32-32-12

15000-18000bph

5.5kw

HSG38-38-14

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.


low cost automatic liquid filling machine 4in1 factory for beverages-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

low cost automatic liquid filling machine 4in1 factory for beverages-3

low cost automatic liquid filling machine 4in1 factory for beverages-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP

Capping Part
The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

low cost automatic liquid filling machine 4in1 factory for beverages-5

low cost automatic liquid filling machine 4in1 factory for beverages-6

Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is the first choice in high-end automatic liquid filling machine industry.
2. Shenzhen EcoPura Water Equipment Co.,Ltd has a sound quality management system, and a complete quality inspection method to ensure the company's quality and reputation.
3. Long-term partnerships with customers is what Shenzhen EcoPura Water Equipment Co.,Ltd pursues. Check it! Providing high-end customer service makes great contribution to the development of EcoPura. Check it! Shenzhen EcoPura Water Equipment Co.,Ltd will provide more cost-effective products as well as more perfect and faster service. Check it!
