latest csd filling machine csd trader for sale

Latest csd filling machine csd trader for sale

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Product Information of latest csd filling machine csd trader for sale
Company Advantages
1. EcoPura bottle filling machine manufacturers has been certified under CE. It also meets the strict standards required in the refrigeration equipment industry and the food retail and services sector. Equipped with a safety system, the product can detect the faults
2. Shenzhen EcoPura Water Equipment Co.,Ltd will provide a broad range of solutions for our csd filling machine . It can be configured in a straight line or in an L-shaped configuration
3. It quality is demonstrated during a rigorous audit process. The product can enhance the speed, accuracy, and efficiency of workers
4. csd filling machine relies on the market demand to continuously innovate and develop. The product is hygiene with no bacteria or mold built up
5. This product meets or exceeds all quality and safety standards. Made of stainless steel materials, the product has a smooth surface to resist dust and dirt
Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L DHSG-series monobloc equipped with isobaric filler nozzles designated for filling carbonated beverages such as Cola, beer, carbonated water and other liquids etc


latest csd filling machine csd trader for sale-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

DHSG16-16-12-6

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

3000-3500bph

1.8kw

SIEMENS

DHSG24-24-16-6

4000-5000bph

2.2kw

DHSG24-24-18-8

5000-6000bph

2.2kw

DHSG24-24-24-8

8000-9000bph

3.0kw

DHSG32-32-32-12

10000-12000bph

5.5kw

DHSG38-38-38-14

12000-15000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

latest csd filling machine csd trader for sale-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316 Contactless filling SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

latest csd filling machine csd trader for sale-3

latest csd filling machine csd trader for sale-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part
Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The PET container is first pressed on by the PET lifting unit and pressurised afterwards. Once the same pressure is in the ring bowl and the PET container, the filling valve will be opened and the filling process starts. The liquid is gently fed via a swirl insert into the bottle. Two different filling speeds guarantee optimum flow behaviour. A flow meter monitors the fed liquid quantity. Once the exact filling volume has been reached, the flow meter provides a signal and the valve closes electro pneumatically Maximum flexibility − Filling of non-carbonated and carbonated products on one system Maximum filling accuracy − Precise determination of fill quantity via inductive flow meter Gentle product treatment during filling − Low-foam and low-turbulence filling vias wirl insert in the valve Hygiene and stable filling processes − Separate gas channels for pressurization and snifting ECOPURA filling machines in their standard version are suitable for CIP and beverage mixer

latest csd filling machine csd trader for sale-5

latest csd filling machine csd trader for sale-6

Capping Part
The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature
Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

latest csd filling machine csd trader for sale-7


Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is one of point key enterprises in Chinese profession's csd filling machine industry.
2. Our company is equipped with an excellent workforce. Most of them have a longstanding career in this industry, thus having a solid understanding of this industry.
3. We have refined a customer-centric belief system, focusing on delivering a positive experience and providing unparalleled levels of attention and support so customers can focus on growing their business.
