Product Information of ISO9001 certified wine bottling equipment machine manufacturer for market
Enterprise Strength
  • EcoPura Water Treatment Equipment & Bottling Machine puts customers first and strives to provide quality and considerate services for customers.
Company Advantages
1. The materials applied in EcoPura wine filler are guaranteed to has strong wear and tear performance as well as leakage tightness, to provide the best longevity for application.
2. The product features high quality. It is not prone to have surface fracturing problem or color fading caused by oxidation even used for a long time.
3. Thanks to its fully advanced operation system, the product effectively cuts down the labor costs as there are fewer workers involved.
4. The use of this product means that it can lower wage costs, energy use and improved use of materials, which will finally help lower production and unit cost.
Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine


ISO9001 certified wine bottling equipment machine manufacturer for market-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG8-8-3G

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

5000-3000bph

1.5kw

SIEMENS

HSG16-12-6G

3000-4500bph

1.8kw

HSG24-16-6G

5000-6000bph

2.2kw

HSG24-18-8G

7000-8000bph

2.2kw

HSG24-24-8G

10000-12000bph

3.0kw

HSG32-32-12G

15000-18000bph

5.5kw

HSG38-38-14G

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

ISO9001 certified wine bottling equipment machine manufacturer for market-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

ISO9001 certified wine bottling equipment machine manufacturer for market-3

ISO9001 certified wine bottling equipment machine manufacturer for market-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part
After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

ISO9001 certified wine bottling equipment machine manufacturer for market-5

ISO9001 certified wine bottling equipment machine manufacturer for market-6

Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. As a professional wine bottling equipment producer, Shenzhen EcoPura Water Equipment Co.,Ltd is greatly recognized among customers.
2. Our factory is equipped with a series of production facilities that have been certified. They ensure that we can manufacture products at the highest level.
3. The service principle of Shenzhen EcoPura Water Equipment Co.,Ltd has always been wine filler . Check it! Shenzhen EcoPura Water Equipment Co.,Ltd offers a whole set of service for wine bottle filler . Check it!
