ISO9001 certified beer bottle filling machine filling purchase online for distribution

ISO9001 certified beer bottle filling machine filling purchase online for distribution

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Product Information of ISO9001 certified beer bottle filling machine filling purchase online for distribution
Product Details
EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment is processed based on advanced technology. It has excellent performances in the following details.EcoPura Water Treatment Equipment & Bottling Machine carries out strict quality monitoring and cost control on each production link of water treatment equipment, from raw material purchase, production and processing and finished product delivery to packaging and transportation. This effectively ensures the product has better quality and more favorable price than other products in the industry.
Enterprise Strength
  • EcoPura Water Treatment Equipment & Bottling Machine strives to provide quality and comprehensive services based on customer demand.
Company Advantages
1. The application of the advanced technology has made EcoPura beer canning machine for sale more perfect on appearance.
2. The product has the advantage of sliding performance. Coated with marine-grade gel and made of fiberglass materials, it is guaranteed enough smoothness.
3. The price of this product is competitive and is now widely used in the market.
Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.0L HSG-B series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine


ISO9001 certified beer bottle filling machine filling purchase online for distribution-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG8-8-3G

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

2000-3000bph

1.5kw

SIEMENS

HSG16-12-6G

3000-4500bph

1.8kw

HSG24-16-6G

5000-6000bph

2.2kw

HSG24-18-8G

7000-8000bph

2.2kw

HSG24-24-8G

10000-12000bph

3.0kw

HSG32-32-12G

15000-18000bph

5.5kw

HSG38-38-14G

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

ISO9001 certified beer bottle filling machine filling purchase online for distribution-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316. hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

ISO9001 certified beer bottle filling machine filling purchase online for distribution-3

ISO9001 certified beer bottle filling machine filling purchase online for distribution-4

Filling Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination
The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Crown Cappe
Once the crown has been fed from the crown chute into the transfer segment, a magnet is used for the further guidance of the crown. A pushing notch is then used to position the crown on the ejection plunger of the capping head. The crowning head is lowered until the crown in the crowning throat is placed on the bottle. The bottle then holds it in place. Afterwards only the crowning throat continues to be lowered. In the first phase, only the force of the guiding springs has any effect on the crown.

ISO9001 certified beer bottle filling machine filling purchase online for distribution-5

ISO9001 certified beer bottle filling machine filling purchase online for distribution-6

Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. EcoPura is unique in being able to quickly respond to beer canning machine for sale , while providing quality assurance.
2. By applying independent technological innovation, the beer bottle filling machine industry developed by EcoPura is more competitive.
3. EcoPura always adheres to the 'three new' policy: new materials, new processes, new technologies. Get price! EcoPura ​​will develop horizontally to meet the needs of the foreign trade market. Get price! The EcoPura brand is now committed to improving the quality of its services. Get price! Shenzhen EcoPura Water Equipment Co.,Ltd will guarantee greater customer satisfaction throughout the purchasing procedure. Get price!
