hot sale automatic liquid filling machine filling trade partner for liquids

hot sale automatic liquid filling machine filling trade partner for liquids
  • hot sale automatic liquid filling machine filling trade partner for liquids
  • hot sale automatic liquid filling machine filling trade partner for liquids
  • hot sale automatic liquid filling machine filling trade partner for liquids
  • hot sale automatic liquid filling machine filling trade partner for liquids
  • hot sale automatic liquid filling machine filling trade partner for liquids
  • hot sale automatic liquid filling machine filling trade partner for liquids
  • hot sale automatic liquid filling machine filling trade partner for liquids
  • hot sale automatic liquid filling machine filling trade partner for liquids

hot sale automatic liquid filling machine filling trade partner for liquids

automatic liquid filling machine is still valuable due to its advantages as water bottling plant . The use of this product helps in increasing the production of drinks
Inquire Online
Get the latest price
Quantity Needed:
Pieces
E-mail:
Company Advantages
1. With unique design, our automatic liquid filling machine can satisfy the pursuits of clients to it. The product features excellent purification technology
2. Even refund is possible if you are not satisfied with our automatic liquid filling machine after buying. The product is equipped with air conveyor and frequency control
3. automatic liquid filling machine is still valuable due to its advantages as water bottling plant . The use of this product helps in increasing the production of drinks
4. automatic liquid filling machine has advantages both in cost, reliability and long life, in comparison with other similar products. Its parts are all made of CNC machines, which features high accuracy
5. After one year's research and development, automatic liquid filling machine has already been used in water bottling plant . The dimension of this product can be customized according to needs
Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc


hot sale automatic liquid filling machine filling trade partner for liquids-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG24-24-16-6

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

5000-6000bph

2.2kw

SIEMENS

HSG24-24-18-8

7000-8000bph

2.2kw

HSG24-24-24-8

10000-12000bph

3.0kw

HSG32-32-32-12

15000-18000bph

5.5kw

HSG38-38-38-14

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

hot sale automatic liquid filling machine filling trade partner for liquids-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

hot sale automatic liquid filling machine filling trade partner for liquids-3

hot sale automatic liquid filling machine filling trade partner for liquids-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part
Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

hot sale automatic liquid filling machine filling trade partner for liquids-5

hot sale automatic liquid filling machine filling trade partner for liquids-6

Capping Part
The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature
Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

hot sale automatic liquid filling machine filling trade partner for liquids-7


Company Features
1. The EcoPura brand is spoken highly of by customers in the industry. We have a dedicated management team. Based on their years of unique management experience, they can improve our manufacturing processes to constantly meet customers' needs.
2. Our quality assurance program has developed nine step quality-checking procedures. We thus make sure that our customers receive garments that will leave them 100% satisfied.
3. We have brought together exceptional sales teams. They are quite professional in offering product solutions to clients with their abundant knowledge of product information as well as market purchasing tendency. Shenzhen EcoPura Water Equipment Co.,Ltd will continue to perform strategic innovation and market creation. Inquire!
The design of EcoPura water bottling plant follows a unified principle, that is, all the basic elements of the design are harmonious and show a sense of unity. The technology used in it brings the image to life
The design of EcoPura water bottling plant is the integration of intelligence and professionalism. The latest cutting-edge technologies such as automation detection and automatic control technologies have been applied to its design. Full view is one of the biggest selling points of this product
EcoPura water bottling plant has a scientific design. Two-dimensional and three-dimensional design in the arrangement of furniture is taken into consideration when designing this product. This product can guarantee no installation gap
EcoPura automatic liquid filling machine consists of various electrical components. They include gears, pistons, engines and other moving parts, all is of high quality. The technology used in it brings the image to life
EcoPura automatic liquid filling machine is the integration of various latest technologies. It is designed by CAD, fabricated under precise CNC machines, equipped with advanced PLC control, etc. It can be customized to fit different model numbers of devices
water bottling plant Meets the fire protection requirements of roofing materials, can reach the flame retardant standard, and can effectively delay the spread of fire in the event of a fire accident.
