hot sale automatic liquid filling machine filling trade partner for commercial production

Company Advantages
1. The rigorous design phase of EcoPura automatic liquid filling machine makes it distinctive. The product can enhance the speed, accuracy, and efficiency of workers
2. The product has a wider and wider market thanks to its above advantages. The operation of this product is controlled by microcomputer
3. A strict quality control system ensures that product quality meets international standards. The product is carefully designed with all NSF approved components
4. As a testament to the great quality, the product is backed by many international quality certificates on a basis of our various performance test and quality assurance test. The product is hygiene with no bacteria or mold built up
5. The products are internationally certified and have a longer service life than other products. The product features a high degree of automation

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

hot sale automatic liquid filling machine filling trade partner for commercial production-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
HSG24-24-18-8		7000-8000bph	2.2kw
HSG24-24-24-8		10000-12000bph	3.0kw
HSG32-32-32-12		15000-18000bph	5.5kw
HSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

hot sale automatic liquid filling machine filling trade partner for commercial production-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

hot sale automatic liquid filling machine filling trade partner for commercial production-3

hot sale automatic liquid filling machine filling trade partner for commercial production-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

hot sale automatic liquid filling machine filling trade partner for commercial production-5

hot sale automatic liquid filling machine filling trade partner for commercial production-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

hot sale automatic liquid filling machine filling trade partner for commercial production-7

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is a children's creative automatic liquid filling machine enterprise with design, research and development and brand operation as its core. As a result of superior quality products and outstanding customer service, we have gained a global sales network reaching many countries, including America, Japan, Russia, Spain, Portugal, South Africa, etc.
2. Our factory has a number of advanced and sophisticated product testing instruments which are approved by authoritative institutions. This has brought to increased product quality and safety guarantee.
3. Our customers range from regional companies to those on National's Top 500 List. By continuously delivering value to our customers we earn long term relationships. In fact, our original customer from our establishing year is still a customer today. All the staff of EcoPura Water Treatment Equipment & Bottling Machine will make unremitting efforts, and bravely climb the peak of small liquid filling machine industry. Get price!

o******h

The production of EcoPura automatic liquid filling machine follows the strict production process.

h******k

EcoPura liquid filling machine is elaborately manufactured using the latest advanced technology and production method.

w******f

EcoPura liquid filling machine is finely manufactured thanks to the applications of advanced technology and lean production system.

y******j

Advanced production technology: liquid filling machine is manufactured following the guidance of lean production method and completed by the combined efforts of advanced equipment and skilled workers.

n******w

In the design of EcoPura liquid filling machine, a professional market survey is carried out according to customers' demands. As a result of innovative ideas and technologies, it is user-friendly.

s******f

This product has the advantages of long service life and excellent performance.
