Product Information of factory directly supply wine filling machine wine trader for distribution
Application Scope
With wide application, water treatment equipment can be used in the following aspects.EcoPura Water Treatment Equipment & Bottling Machine has been engaged in the production of water treatment equipment for many years and has accumulated rich industry experience. We have the ability to provide comprehensive and quality solutions according to actual situations and needs of different customers.
Product Details
EcoPura Water Treatment Equipment & Bottling Machine pays great attention to product quality and strives for perfection in every detail of products. This enables us to create fine products.EcoPura Water Treatment Equipment & Bottling Machine has great production capability and excellent technology. We also have comprehensive production and quality inspection equipment. bottle filling machine has fine workmanship, high quality, reasonable price, good appearance, and great practicality.
Company Advantages
1. The design of EcoPura wine filter machine is done by the professional designers who are skillful in identifying and distilling the best elements from different tableware cultures and transforming them into reality.
2. This product has functional safety. Possible failures or faults which could lead to a hazard are analyzed in detail in the manufacture, hence they are eliminated or reduced in use.
3. The product is safe to use. It has been checked under anti-static testing and materials elements inspection to ensure users' safety.
4. Shenzhen EcoPura Water Equipment Co.,Ltd connects wine filling machine products and services to supporting the customers.
5. Shenzhen EcoPura Water Equipment Co.,Ltd is much more like a scalable and sustainable organization.
Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine


factory directly supply wine filling machine wine trader for distribution-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG8-8-3G

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

5000-3000bph

1.5kw

SIEMENS

HSG16-12-6G

3000-4500bph

1.8kw

HSG24-16-6G

5000-6000bph

2.2kw

HSG24-18-8G

7000-8000bph

2.2kw

HSG24-24-8G

10000-12000bph

3.0kw

HSG32-32-12G

15000-18000bph

5.5kw

HSG38-38-14G

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

factory directly supply wine filling machine wine trader for distribution-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

factory directly supply wine filling machine wine trader for distribution-3

factory directly supply wine filling machine wine trader for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part
After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

factory directly supply wine filling machine wine trader for distribution-5

factory directly supply wine filling machine wine trader for distribution-6

Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Being a dependable manufacturer, Shenzhen EcoPura Water Equipment Co.,Ltd has been providing wine filter machine . We have been engaged in production and distribution.
2. EcoPura owns its own factory to produce wine filling machine with high quality.
3. It is indispensable for EcoPura to develop its enterprise culture. Inquire online! To better serve customers, EcoPura especially has its own professional service team. Inquire online! We have been concentrating on serving customers with our best wine bottling equipment and considerate service. Inquire online!
