factory directly supply wine bottling machine filling factory for distribution

Factory directly supply wine bottling machine filling factory for distribution

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Product Information of factory directly supply wine bottling machine filling factory for distribution
Product Details
EcoPura Water Treatment Equipment & Bottling Machine's bottling line is perfect in every detail.EcoPura Water Treatment Equipment & Bottling Machine's bottling line is manufactured in strict accordance with relevant national standards. Every detail matters in the production. Strict cost control promotes the production of high-quality and priced-low product. Such a product is up to customers' needs for a highly cost-effective product.
Enterprise Strength
  • EcoPura Water Treatment Equipment & Bottling Machine is committed to providing quality and efficient pre-sales, sales, and after-sales services for customers.
Company Advantages
1. The design style of EcoPura wine bottling machine keeps abreast of the popular trends.
2. The product is of high quality and can withstand stringent quality and performance tests.
3. Different kinds of high-quality supply chains are Shenzhen EcoPura Water Equipment Co.,Ltd's solid defense.
4. Shenzhen EcoPura Water Equipment Co.,Ltd offers a variety of special OEM and ODM programs on wine bottling machine .
Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine


factory directly supply wine bottling machine filling factory for distribution-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG8-8-3G

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

5000-3000bph

1.5kw

SIEMENS

HSG16-12-6G

3000-4500bph

1.8kw

HSG24-16-6G

5000-6000bph

2.2kw

HSG24-18-8G

7000-8000bph

2.2kw

HSG24-24-8G

10000-12000bph

3.0kw

HSG32-32-12G

15000-18000bph

5.5kw

HSG38-38-14G

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

factory directly supply wine bottling machine filling factory for distribution-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

factory directly supply wine bottling machine filling factory for distribution-3

factory directly supply wine bottling machine filling factory for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part
After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

factory directly supply wine bottling machine filling factory for distribution-5

factory directly supply wine bottling machine filling factory for distribution-6

Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. EcoPura owns a unique competitive advantage in the field of wine bottling machine .
2. Shenzhen EcoPura Water Equipment Co.,Ltd has advanced facilities.
3. We actively assume environmental responsibility and will gear our production towards a cleaner, sustainable, and more environmental-friendly way. Environment protection is the priority of our business. We undertake active measures while utilizing our technological expertise and other resources to contribute to advancement. Looking to the future, we are pursuing the spirit of 'pioneering and innovative spirit'. We will make every effort to produce more quality products and offer considerate service to the customers and society. Our company makes environmental protection a top priority. In our production, dust and liquid waste are collected and incinerated to ensure that they are not discharged into the environment.
