factory directly supply wine bottling equipment filling manufacturer for market

Factory directly supply wine bottling equipment filling manufacturer for market

Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Product Information of factory directly supply wine bottling equipment filling manufacturer for market
Application Scope
EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine is widely used in the Manufacturing Machinery industry and is widely recognized by customers.EcoPura Water Treatment Equipment & Bottling Machine has an excellent team consisting of talents in R&D, production and management. We could provide practical solutions according to actual needs of different customers.
Product Comparison
Under the guidance of market, EcoPura Water Treatment Equipment & Bottling Machine constantly strives for innovation. bottling line has reliable quality, stable performance, good design, and great practicality.bottling line in EcoPura Water Treatment Equipment & Bottling Machine has the following advantages, compared with same kind of products in the market.
Company Advantages
1. EcoPura wine filler is manufactured by using superior quality raw material and progressive technology under the vigilance of proficient professionals.
2. The product has good temperature withstanding capability. Its mechanical properties will not be affected by the variations in temperature.
3. The product is built to last. It is made of heavy-duty materials which can withstand the most rigorous industrial conditions.
4. The product can be used in many fields and has huge market potential.
5. The product, having great economic benefits, is popular among the clients.
Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine


factory directly supply wine bottling equipment filling manufacturer for market-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG8-8-3G

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

5000-3000bph

1.5kw

SIEMENS

HSG16-12-6G

3000-4500bph

1.8kw

HSG24-16-6G

5000-6000bph

2.2kw

HSG24-18-8G

7000-8000bph

2.2kw

HSG24-24-8G

10000-12000bph

3.0kw

HSG32-32-12G

15000-18000bph

5.5kw

HSG38-38-14G

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

factory directly supply wine bottling equipment filling manufacturer for market-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

factory directly supply wine bottling equipment filling manufacturer for market-3

factory directly supply wine bottling equipment filling manufacturer for market-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part
After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

factory directly supply wine bottling equipment filling manufacturer for market-5

factory directly supply wine bottling equipment filling manufacturer for market-6

Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. It is known from the comparison that Shenzhen EcoPura Water Equipment Co.,Ltd is advanced in wine bottling equipment industry .
2. Our production capacity occupies steadily in the forefront of the wine bottling machine industry.
3. With “to stay ahead of the curve” firmly in mind, committed to providing customers with thoughtful service and reliable quality products. It is our goal to maintain the highest levels of quality in the product we manufacture, in our equipment, in our plant, and among our workers. Our goal is to create value – for our customers and consumers, for our teams, as well as for the wider society and communities in which we operate. We put forth efforts to reduce carbon emissions in our production. By showing that we care about improving and preserving the environment, we aim to gain more support and business and also build a solid reputation as an environmental leader.
