hot sale small liquid filling machine water manufacturer for liquids

Product Details

With a focus on quality, EcoPura Water Treatment Equipment & Bottling Machine pays great attention to the details of water treatment equipment.EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment is manufactured in strict accordance with relevant national standards. Every detail matters in the production. Strict cost control promotes the production of high-quality and priced-low product. Such a product is up to customers' needs for a highly cost-effective product.

Application Scope

EcoPura Water Treatment Equipment & Bottling Machine's bottling line can be used in different fields.EcoPura Water Treatment Equipment & Bottling Machine insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.

Company Advantages
1. EcoPura small liquid filling machine is manufactured adopting CNC machines. Programs for the CNC machines are created in advance by our dedicated CAD/CAM specialists working with the latest equipment.
2. The product features accurate specifications. It usually has tight tolerances in order to match up to other parts or assembly.
3. Shenzhen EcoPura Water Equipment Co.,Ltd has established a globally independent brand with superior products and services.
4. With excellent R&D team and large scale production, Shenzhen EcoPura Water Equipment Co.,Ltd leads the modern small liquid filling machine industry trend.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura water small liquid filling machine manufacturer for liquids-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3	0.33L-1.5L Height:150-330mm Dia: 50-115mm	2000-3000bph	1.5kw	SIEMENS
HSG16-12-6		3000-4500bph	1.8kw
HSG24-16-6		5000-6000bph	2.2kw
HSG24-18-8		7000-8000bph	2.2kw
HSG24-24-8		10000-12000bph	3.0kw
HSG32-32-12		15000-18000bph	5.5kw
HSG38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura water small liquid filling machine manufacturer for liquids-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura water small liquid filling machine manufacturer for liquids-3

EcoPura water small liquid filling machine manufacturer for liquids-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura water small liquid filling machine manufacturer for liquids-5

EcoPura water small liquid filling machine manufacturer for liquids-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd enjoys a crucial status in market of small liquid filling machine for its high quality and big capacity.
2. Shenzhen EcoPura Water Equipment Co.,Ltd is widely known for its scientific search and technology ability.
3. Creating value for both EcoPura and customers is a motivation for the development of company. Get an offer! With the goal of becoming stronger in the future, EcoPura aims to provide the best automatic liquid filling machine and service for customers. Get an offer! Shenzhen EcoPura Water Equipment Co.,Ltd will continue our path towards green and low-carbon sustainable development. Get an offer! Shenzhen EcoPura Water Equipment Co.,Ltd manages itself under the tenet of 'Seeking Innovation and Development'. Get an offer!

e******w

EcoPura liquid filling machine is made of selected materials that are of high quality.

a******l

EcoPura small liquid filling machine is delicately manufactured by combining the best materials and the lean production method.

k******w

EcoPura automatic liquid filling machine has attracting designs with consistency.

r******c

EcoPura small liquid filling machine is the result of integrating the wisdom of our creative designers. In terms of its design, it follows the latest market trend, making it outperform over half of the similar products in the market.

r******l

EcoPura small liquid filling machine is manufactured using state-of-the-art technology based on the principles of lean production.

q******u

liquid filling machine material greatly improve the performance of automatic liquid filling machine and furthermore it is low costing.
