low cost small liquid filling machine 3in1 factory for liquids

Application Scope

EcoPura Water Treatment Equipment & Bottling Machine's bottling line is widely used in the Manufacturing Machinery industry.EcoPura Water Treatment Equipment & Bottling Machine is dedicated to solving your problems and providing you with one-stop and comprehensive solutions.

Company Advantages
1. The design of EcoPura liquid filling machine is finely finished. Its details are carefully mapped out in terms of material, dimensions, shape, thickness, etc.
2. This product is corrosion resistant. It has been tested in salt fog harsh environment to determine its resistance to the effects of a salt atmosphere.
3. Less time and effort are needed to maintain this product over the years, therefore one can save energy and costs.
4. This product has proved a great blessing to the workers. It makes human muscles relieved. Therefore, the work of the laborer has become much lighter.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura low cost small liquid filling machine factory for liquids-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3	0.33L-1.5L Height:150-330mm Dia: 50-115mm	2000-3000bph	1.5kw	SIEMENS
HSG16-12-6		3000-4500bph	1.8kw
HSG24-16-6		5000-6000bph	2.2kw
HSG24-18-8		7000-8000bph	2.2kw
HSG24-24-8		10000-12000bph	3.0kw
HSG32-32-12		15000-18000bph	5.5kw
HSG38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura low cost small liquid filling machine factory for liquids-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura low cost small liquid filling machine factory for liquids-3

EcoPura low cost small liquid filling machine factory for liquids-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura low cost small liquid filling machine factory for liquids-5

EcoPura low cost small liquid filling machine factory for liquids-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. As a well-known company on the market, Shenzhen EcoPura Water Equipment Co.,Ltd is now a leader in the small liquid filling machine industry.
2. Our products sell well in the United States, Canada, Japan, Australia, and many other countries. It is the high quality, together with the attentive services that help us win such a large number of customers.
3. Shenzhen EcoPura Water Equipment Co.,Ltd is quality-oriented and customer-oriented. Check now! Our professional team in Shenzhen EcoPura Water Equipment Co.,Ltd will provide professional service for our customers. Check now! Shenzhen EcoPura Water Equipment Co.,Ltd has redoubled its efforts to develop next-generation technologies and services to continuously benefit customers. Check now!
