low cost bottle filler bottling factory for commercial production

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine provides complete services for customers with professional, sophisticated, reasonable and fast principles.

Application Scope

EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine can be applied to different fields and scenes, which enables us to meet different requirements.With many years of practical experience, EcoPura Water Treatment Equipment & Bottling Machine is capable of providing comprehensive and efficient one-stop solutions.

Company Advantages
1. Shenzhen EcoPura Water Equipment Co.,Ltd features its special design for bottle filler .
2. water bottling plant are the characteristics of bottle filler .
3. This bottle filler is especially practical for water bottling plant .
4. bottle filler will require regular maintenance to keep it at their best.
5. At present, Shenzhen EcoPura Water Equipment Co.,Ltd has established a sales network.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura low cost bottle filler factory for commercial production-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3	0.33L-1.5L Height:150-330mm Dia: 50-115mm	2000-3000bph	1.5kw	SIEMENS
HSG16-12-6		3000-4500bph	1.8kw
HSG24-16-6		5000-6000bph	2.2kw
HSG24-18-8		7000-8000bph	2.2kw
HSG24-24-8		10000-12000bph	3.0kw
HSG32-32-12		15000-18000bph	5.5kw
HSG38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura low cost bottle filler factory for commercial production-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura low cost bottle filler factory for commercial production-3

EcoPura low cost bottle filler factory for commercial production-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura low cost bottle filler factory for commercial production-5

EcoPura low cost bottle filler factory for commercial production-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd focuses on a collection of development, design, production of water bottling plant . The company is a rapidly growing enterprise in this industry.
2. Our technology is always one step ahead than other companies for bottle filler .
3. Innovation is the soul of Shenzhen EcoPura Water Equipment Co.,Ltd and the eternal motive force of our career development. Inquiry! We cling to the responsibility of consistent high quality small liquid filling machine. Inquiry!

Technical parameters

Product Description

It adopting the cylinder axis for fast and accurate filing volume adjustment .Conveyer belt and panel made of stainless steel are durable, cleanly. It’s easy for bottle of different size changes and cleaning. Bottle feeding and positioning are air-controlled. Infinite speed adjusted motor makes speed changing freely. It is suitable for individual operation and connected with the production line. No bottle no-filling device.The machine adopted a volumetric piston filling mechanism which is a straight-line model of smooth and automatic bottle feed in.

u******o

Shenzhen EcoPura Water Equipment Co.,Ltd There are modern workshops, standardized production workshops, automated production equipment, strict quality inspection system, etc., which can ensure that all bottle filler produced by our company are of qualified and high quality.

a******q

The company attaches great importance to product quality and strives for excellence in all aspects of production. The bottle filler produced are exquisite in workmanship, excellent in quality and strong in practicability.

w******n

Shenzhen EcoPura Water Equipment Co.,Ltd In the manufacturing of water bottling plant, we have strict requirements and strive for excellence. We not only strictly control the raw materials, but also establish a quality inspection system in accordance with international relevant product testing standards to ensure that every product we sell is qualified and of high quality. Up to standard.

p******t

Shenzhen EcoPura Water Equipment Co.,Ltd Always put product quality first, not only select high-quality raw materials and use advanced production technology to manufacture water bottling plant, but also set up a professional quality inspection team to strictly monitor each production link and each production process, To ensure that the water bottling plant produced are of high quality.

e******n

The company has strong strength and strict management. It not only has a standardized production workshop, but also has established a perfect quality management system. From the selection of raw materials to the delivery of finished products, the quality is strictly controlled in every link to ensure the excellent quality of water bottling plant.

a******l

This product is effective in resisting humidity. It will be not easily affected by the moisture that could lead to the loosening and weakening of joints or even failure. Its ability to take on the three-dimensional form allows it to create textured 3D effects
