low cost bottle filler water factory for beverages

Application Scope

As one of EcoPura Water Treatment Equipment & Bottling Machine's main products, bottle filling machine has wide applications. It is mainly used in the following aspects.EcoPura Water Treatment Equipment & Bottling Machine is dedicated to solving your problems and providing you with one-stop and comprehensive solutions.

Company Advantages
1. EcoPura bottle filler is strictly assessed after production. Many factors include part tolerances, size limitations, materials properties, mechanical analysis, and function realization have been analyzed.
2. Adopting the advanced testing equipment to inspect the product during the production process guarantees the great performance and consistent quality of the product.
3. Shenzhen EcoPura Water Equipment Co.,Ltd has guided itself improving quality management systems.
4. Shenzhen EcoPura Water Equipment Co.,Ltd receives a double reputation from customers and the market and enjoyed a high popularity.

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura low cost bottle filler factory for beverages-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
HSG24-24-18-8		7000-8000bph	2.2kw
HSG24-24-24-8		10000-12000bph	3.0kw
HSG32-32-32-12		15000-18000bph	5.5kw
HSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura low cost bottle filler factory for beverages-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura low cost bottle filler factory for beverages-3

EcoPura low cost bottle filler factory for beverages-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

EcoPura low cost bottle filler factory for beverages-5

EcoPura low cost bottle filler factory for beverages-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura low cost bottle filler factory for beverages-7

Company Features
1. By providing quality bottle filler at a reasonable price, Shenzhen EcoPura Water Equipment Co.,Ltd has been widely acknowledged in the worldwide industry.
2. We have a professional engineer team to design our own products and carry out customization according to clients requirements. The engineers are quite acquainted with the trends and buyers' tendency in this industry.
3. EcoPura is committed to providing more advanced technologies, better liquid filling machine and more thoughtful services, and helping fuel the development of society. Ask online! To be a promoter of the automatic liquid filling machine industry chain, and a contributor in this field is the mission of EcoPura. Ask online! water bottling plant is the management tenet from the first beginning. Ask online! Shenzhen EcoPura Water Equipment Co.,Ltd promises prompt delivery. Ask online!

ModelCapacityMotor PowerZPC-12 GFP-12 YQX-31000-2000B/H3.05KWZPC-12 GFP-12 YQX-42000-4000B/H4.07KWZPC-12 GFP-12 YQX-53000-8000B/H4.82KW

Glass bottleD carbonated soft drink filling machine, CO2 drink filler

Our advantage

Why choice us?

Design Ability	All the machines designed by CAD
Manufacturing Ability	Mechanical parts: high quality stainless steel, processed by CNC
Reliability	Electrical parts from world famous suppliers
Professional	Focus on beverage and cosmetics packing machines Exported to over 20 countries with good reputation 6 years Alibaba Golden supplier without complaint
Good Service	Service include complete production line design, manufacturing, on-site installation & aftersales maintenance.
Profession on Export	Authorized export licence.

r******p

Shenzhen EcoPura Water Equipment Co.,Ltd Relying on years of accumulated production experience, strong technology and research and development strength, advanced equipment and production lines, it is more handy in the production and manufacturing of automatic liquid filling machine, knowing how to reasonably supervise and control each production step and process, Provide guarantee for the production of high-quality products.

z******k

Shenzhen EcoPura Water Equipment Co.,Ltd has many years of production experience, exquisite production technology, strong production strength, and can produce high-quality water bottling plant.

t******f

Shenzhen EcoPura Water Equipment Co.,Ltd has a modern production workshop and advanced bottle filler production equipment, and has established a strict quality management system, and quality inspection personnel will conduct inspections in every link of bottle filler production to ensure bottle filler good quality and high quality excellent.

c******n

The company attaches great importance to product quality and strives for excellence in all aspects of production. The water bottling plant produced are exquisite in workmanship, excellent in quality and strong in practicability.

s******l

Shenzhen EcoPura Water Equipment Co.,Ltd Passed various relevant national certifications, automatic liquid filling machine produced have relevant quality inspection certificates, the quality of the products is guaranteed, and customers are more assured in purchasing.

w******v

It has the required colorfastness. It can withstand the normal cleaning/dry cleaning cycle without fading. The product provides a high-accuracy testing result
