hot sale automatic liquid filling machine water trade partner for liquids

Company Advantages
1. EcoPura liquid filling machine is manufactured with the support of a team of experts. The product is equipped with a high-efficiency operation system
2. This product has broad market possibilities and potential. Its parts are all made of CNC machines, which features high accuracy
3. The product stands out for its stable operation. Since it is mainly controlled by microcomputers, it can run stably without any break. The product has been certified under UL and CE
4. This product has a precise dimension. Its manufacturing process adopts the CNC machines and advanced technologies, which guarantee its accuracy in size and shape. Adopting an advanced touch screen, it is easy to use

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura hot sale automatic liquid filling machine trade partner for liquids-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
HSG24-24-18-8		7000-8000bph	2.2kw
HSG24-24-24-8		10000-12000bph	3.0kw
HSG32-32-32-12		15000-18000bph	5.5kw
HSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura hot sale automatic liquid filling machine trade partner for liquids-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura hot sale automatic liquid filling machine trade partner for liquids-3

EcoPura hot sale automatic liquid filling machine trade partner for liquids-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

EcoPura hot sale automatic liquid filling machine trade partner for liquids-5

EcoPura hot sale automatic liquid filling machine trade partner for liquids-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura hot sale automatic liquid filling machine trade partner for liquids-7

Company Features
1. EcoPura has become one of the most popular manufacturers in the automatic liquid filling machine industry. EcoPura has established the complete system to guarantee the quality of small liquid filling machine.
2. EcoPura constantly optimizes bottle filler production technologies.
3. EcoPura has been focusing on improving the quality of automatic liquid filling machine . liquid filling machine is an important action as good customer service for Shenzhen EcoPura Water Equipment Co.,Ltd. Welcome to visit our factory!

f******l

EcoPura liquid filling machine is superior in raw materials: inferior raw materials are totally rejected into the factory. And the high quality raw materials are well accepted though they will increase the cost of production. The product adopts a unique and modern design

r******s

The appearance design of EcoPura bottle filler is carried out by our designers who have the ultimate pursuit of performance and aesthetics to enable the product meets the market demands. The product is characterized by a high resolution

c******l

Crafted precisely in our modernized facility, EcoPura small liquid filling machine is manufactured with the finest workmanship at a lower cost. The product is very safe to operate

e******c

Standard manufacturing: the production of EcoPura automatic liquid filling machine is based on the advanced technology developed by ourselves autonomously and the complete management system and standards. The product adopts a water cooling system for better performance

a******h

EcoPura automatic liquid filling machine has the compliant design throughout its lifecycle. The product ensures stable and reliable performance

z******l

Made from high-quality materials, small liquid filling machine has strong corrosion resistance, low contact resistance with active materials, good deep discharge performance and good charge acceptance. It is a durable and superior product that is widely favored by customers.
