hot sale small liquid filling machine filling manufacturer for commercial production

Product Comparison

bottle filling machine, manufactured based on high-quality materials and advanced technology, has reasonable structure, excellent performance, stable quality, and long-lasting durability. It is a reliable product which is widely recognized in the market.Compared with products in the same category, bottle filling machine's core competencies are mainly reflected in the following aspects.

Application Scope

EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment is of excellent quality and is widely used in the Manufacturing Machinery industry.EcoPura Water Treatment Equipment & Bottling Machine is dedicated to providing professional, efficient and economical solutions for customers, so as to meet their needs to the greatest extent.

Company Advantages
1. EcoPura water filling is developed integrating with many technologies such as biometrics, RFID, and self-checkouts, which are widely used in the POS system field.
2. The product runs stably and reliably. It is not prone to the effects of sudden surges, susceptibility driven, gaps, interruptions, and voltage variations.
3. Shenzhen EcoPura Water Equipment Co.,Ltd knows that only quality can win us more customers like you that pays attention to it.
4. Shenzhen EcoPura Water Equipment Co.,Ltd provides customer service of quality consultations.

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura filling small liquid filling machine manufacturer for commercial production-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
HSG24-24-18-8		7000-8000bph	2.2kw
HSG24-24-24-8		10000-12000bph	3.0kw
HSG32-32-32-12		15000-18000bph	5.5kw
HSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura filling small liquid filling machine manufacturer for commercial production-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura filling small liquid filling machine manufacturer for commercial production-3

EcoPura filling small liquid filling machine manufacturer for commercial production-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

EcoPura filling small liquid filling machine manufacturer for commercial production-5

EcoPura filling small liquid filling machine manufacturer for commercial production-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura filling small liquid filling machine manufacturer for commercial production-7

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is very competitive in manufacturing and marketing water filling . We are known as one of the pioneers in this industry.
2. The internal quality management system has existed since the very first days of the factory's activity. This system targets controlling the entire range of production activities to ensure high product quality.
3. liquid filling machine is the core value of the brand EcoPura. Ask online! EcoPura adheres to the core concept of water bottling plant and regards bottling machine as the core values. Ask online! Shenzhen EcoPura Water Equipment Co.,Ltd contributes to the society with the collective strength of the company. Ask online!

b******d

The raw materials of EcoPura water bottling plant is extremely strict selection.

o******n

EcoPura water bottling plant has a wide selection of high-quality materials.

z******w

EcoPura liquid filling machine is precisely designed using premium quality raw material and leading-edge technology.

g******p

The raw materials of EcoPura bottling machine are sourced from the reputed vendors of the market.

x******v

The raw materials EcoPura bottling machine uses is selected by professional experts.

a******b

The product is exceptional in terms of durability and requires the least maintenance.
