affordable small liquid filling machine filling manufacturer for beverages

Company Advantages
1. In the creation of EcoPura liquid filling machine , advanced equipment is adopted. The equipment involves a CNC machine, mold shaping machine, stamping machine, and welding machine. Its parts are all made of CNC machines, which features high accuracy
2. Shenzhen EcoPura Water Equipment Co.,Ltd has established a strict quality guarantee system and obtained a few related quality guarantee certifications as well.
3. The product features nonporous constructions. It is made of fine particle clay which can result in a thin construction and translucent body with very small porosity. The product can ensure a high filtration rate
4. The product is able to provide a great purifying effect. The multi-medium beforehand filter helps to increase the capacity of water treatment. The product is widely used for commercial applications
5. The product is safe enough. Its housing performs well in preventing water or moisture from entering into the inner part, posing no electric shock hazard. The product generates little noise during operation

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura filling small liquid filling machine manufacturer for beverages-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3	0.33L-1.5L Height:150-330mm Dia: 50-115mm	2000-3000bph	1.5kw	SIEMENS
HSG16-12-6		3000-4500bph	1.8kw
HSG24-16-6		5000-6000bph	2.2kw
HSG24-18-8		7000-8000bph	2.2kw
HSG24-24-8		10000-12000bph	3.0kw
HSG32-32-12		15000-18000bph	5.5kw
HSG38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura filling small liquid filling machine manufacturer for beverages-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura filling small liquid filling machine manufacturer for beverages-3

EcoPura filling small liquid filling machine manufacturer for beverages-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura filling small liquid filling machine manufacturer for beverages-5

EcoPura filling small liquid filling machine manufacturer for beverages-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is state-designated comprehensive manufacture of small liquid filling machine.
2. We have been working with customers from different countries for many years, such as Europe and the United States. Now, we are expanding the marketing channels to cover more countries including Japan, Germany, and Korean.
3. Shenzhen EcoPura Water Equipment Co.,Ltd will continue to provide quality service and create a good cooperation environment for companies of various kinds. Get more info!

n******u

The production of EcoPura small liquid filling machine follows the strict production process.

f******o

EcoPura liquid filling machine is elaborately manufactured using the latest advanced technology and production method.

u******x

EcoPura small liquid filling machine is finely manufactured thanks to the applications of advanced technology and lean production system.

b******n

Advanced production technology: small liquid filling machine is manufactured following the guidance of lean production method and completed by the combined efforts of advanced equipment and skilled workers.

s******a

In the design of EcoPura small liquid filling machine, a professional market survey is carried out according to customers' demands. As a result of innovative ideas and technologies, it is user-friendly.

p******n

This product has the advantages of long service life and excellent performance.
