low cost small liquid filling machine bottling trade partner for liquids

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine sincerely provides quality and comprehensive services for the vast number of customers. We receive unanimous acclaim from customers.

Company Advantages
1. The manufacture of EcoPura water bottling plant complies with the safety standard. Tests carried out on fabric selection, structure and accessories ensure the safety of the finished product.
2. The product is highly wear-resistant. Its abrasion-resistant coating can provide a thin layer of lubrication to prevent parts to wear out.
3. The product works stably under severe conditions. It is highly resistant to high and low temperature and abnormal pressure working conditions.
4. Shenzhen EcoPura Water Equipment Co.,Ltd constantly advancing with the times in small liquid filling machine field.

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura bottling small liquid filling machine trade partner for liquids-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
HSG24-24-18-8		7000-8000bph	2.2kw
HSG24-24-24-8		10000-12000bph	3.0kw
HSG32-32-32-12		15000-18000bph	5.5kw
HSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura bottling small liquid filling machine trade partner for liquids-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura bottling small liquid filling machine trade partner for liquids-3

EcoPura bottling small liquid filling machine trade partner for liquids-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

EcoPura bottling small liquid filling machine trade partner for liquids-5

EcoPura bottling small liquid filling machine trade partner for liquids-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura bottling small liquid filling machine trade partner for liquids-7

Company Features
1. With excellent manufacturing ability, Shenzhen EcoPura Water Equipment Co.,Ltd has created high-quality water bottling plant that makes itself stand out in the market.
2. By performing high technology, EcoPura is able to ensure the quality of the small liquid filling machine.
3. We cling to the responsibility of consistent high quality bottle filler . Please contact us! EcoPura has been exerting itself to being an experienced and technical automatic liquid filling machine supplier. Please contact us! Shenzhen EcoPura Water Equipment Co.,Ltd will continuously carry out strategic innovation and market innovation. Please contact us! High quality small liquid filling machine is the prerequisite for EcoPura to develop in the oversea market. Please contact us!

h******x

Strict quality inspection for EcoPura automatic liquid filling machine will be conducted by the QC team. The inspection aims to make sure all the stitching and seaming are consistent and symmetrical, the top fly is straight, the seal is tight and tidy, and the lines are uniform. It can be designed with a brake system to prevent moving when not desired

w******t

The main tests are carried out when testing EcoPura water bottling plant. These tests include adhesion tests, color fastness tests, assembly tests, and adhesion tests for signs and labels. Parts that are in contact with people, such as the handle, are ergonomically designed

l******x

EcoPura automatic liquid filling machine has been 100% tested in terms of many aspects. They mainly are care labeling, colorfastness, fabric construction, dimensional stability, etc. It brings a smooth and noise reduced running

i******h

EcoPura small liquid filling machine has passed the comprehensive performance test. They include durability tests, stability tests, precision tests, safety tests, etc. Its materials include laser-cut steel, stainless steel, and aluminum

f******l

The design of EcoPura bottle filler reveals its sophistication and consideration. It is designed in a human-oriented manner that is widely pursued in the furniture industry. It is designed to be lightweight and supportive

r******g

The product is widely recognized for good reliability and usability. Its compact design permits it to be pushed and guided safely and easily through narrow passages
