EcoPura bottling small liquid filling machine manufacturer for beverages

EcoPura bottling small liquid filling machine manufacturer for beverages
  • EcoPura bottling small liquid filling machine manufacturer for beverages
  • EcoPura bottling small liquid filling machine manufacturer for beverages
  • EcoPura bottling small liquid filling machine manufacturer for beverages
  • EcoPura bottling small liquid filling machine manufacturer for beverages
  • EcoPura bottling small liquid filling machine manufacturer for beverages
  • EcoPura bottling small liquid filling machine manufacturer for beverages
  • EcoPura bottling small liquid filling machine manufacturer for beverages

EcoPura bottling small liquid filling machine manufacturer for beverages

Shenzhen EcoPura Water Equipment Co.,Ltd is a best producer and businessperson of bottling machine. In many success stories, we are a suitable partner for our partners. Now the capital technology of Shenzhen EcoPura Water Equipment Co.,Ltd is abundant.
Inquire Online
Get the latest price
Quantity Needed:
Pieces
E-mail:
Company Advantages
1. EcoPura bottling machine has a professional design. It is created by professionals who understand the fundamentals of designing the most commonly used parts, elements, and units of various machines. The product is able to provide a great purifying effect
2. The use of this product enables manufacturers to more focus on their core design and product development, rather than racking their brains to find a way to improve productivity. It can be configured in a straight line or in an L-shaped configuration
3. 100% attention is paid to its performance improvement. With a compact structure, the product can operate stably
4. The product is tested at various stages of development. The product is widely used for commercial applications
5. The product is accurately manufactured to the highest quality standard. The product is carefully designed with all NSF approved components
Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc


EcoPura bottling small liquid filling machine manufacturer for beverages-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG8-8-3

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

2000-3000bph

1.5kw

SIEMENS

HSG16-12-6

3000-4500bph

1.8kw

HSG24-16-6

5000-6000bph

2.2kw

HSG24-18-8

7000-8000bph

2.2kw

HSG24-24-8

10000-12000bph

3.0kw

HSG32-32-12

15000-18000bph

5.5kw

HSG38-38-14

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.


EcoPura bottling small liquid filling machine manufacturer for beverages-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura bottling small liquid filling machine manufacturer for beverages-3

EcoPura bottling small liquid filling machine manufacturer for beverages-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP

Capping Part
The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura bottling small liquid filling machine manufacturer for beverages-5

EcoPura bottling small liquid filling machine manufacturer for beverages-6

Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is a best producer and businessperson of bottling machine. In many success stories, we are a suitable partner for our partners. Now the capital technology of Shenzhen EcoPura Water Equipment Co.,Ltd is abundant.
2. Due to the efforts of skilled technicians, small liquid filling machine have become more competitive in this industry.
3. EcoPura uses the most innovative technology. With the excellent service, EcoPura Water Treatment Equipment & Bottling Machine is highly valued by customers at home and abroad. Call now!
In Shenzhen EcoPura Water Equipment Co.,Ltd, you can have multiple choices for shapes of bottling machine.
small liquid filling machine are equipped with the most advanced small liquid filling machine which is easy to be installed.
The raw material of small liquid filling machine is small liquid filling machine and has the advantages of small liquid filling machine.
If you can provide drawing for small liquid filling machine, Shenzhen EcoPura Water Equipment Co.,Ltd can design and develop for you based on your requirements.
The advantages of our small liquid filling machine include small liquid filling machine.
The product comes with a very smooth fabric as all the short fibers which would cause coarse are removed during the manufacturing process.
