low cost automatic liquid filling machine bottling manufacturer for liquids

Application Scope

EcoPura Water Treatment Equipment & Bottling Machine's bottling line is widely used and can be applied to all walks of life.With a focus on customers, EcoPura Water Treatment Equipment & Bottling Machine analyzes problems from the perspective of customers and provides comprehensive, professional and excellent solutions.

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine is commonly praised in the market due to good materials, fine workmanship, reliable quality, and favorable price.bottle filling machine is more competitive than other products in the same category, as shown in the following aspects.

Company Advantages
1. The production of EcoPura liquid filling machine is strictly carried out. It is treated under high temperature and high pressure to ensure the best luminous efficiency.
2. Our automatic liquid filling machine has been applied to liquid filling machine . It application shows that it is provided with water bottling plant .
3. Through the strict test upon automatic liquid filling machine , the quality of it can be guaranteed.

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura bottling automatic liquid filling machine manufacturer for liquids-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
HSG24-24-18-8		7000-8000bph	2.2kw
HSG24-24-24-8		10000-12000bph	3.0kw
HSG32-32-32-12		15000-18000bph	5.5kw
HSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura bottling automatic liquid filling machine manufacturer for liquids-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura bottling automatic liquid filling machine manufacturer for liquids-3

EcoPura bottling automatic liquid filling machine manufacturer for liquids-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

EcoPura bottling automatic liquid filling machine manufacturer for liquids-5

EcoPura bottling automatic liquid filling machine manufacturer for liquids-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura bottling automatic liquid filling machine manufacturer for liquids-7

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd has been always catering to the needs of society to develop higher-end automatic liquid filling machine .
2. Shenzhen EcoPura Water Equipment Co.,Ltd has advanced production equipment, excellent manufacturing technology and complete testing methods.
3. Our mission is to manufacture and deliver world-class quality products and provide excellent and reliable services, and ultimately create a company that will provide long-term value for customers. Get info! After we have adopted the energy management plan which was rigorously evaluated for its reasonability. Since then, we have improved water efficiency by 20% during production. It is thought that EcoPura will developed into a global number one liquid filling machine brand. Get info! In the future, we will implement business management, strengthen core competencies, and enhance equipment, technology, management and R&D capabilities to improve operational performance. Get info!
