affordable bottle filler 4in1 factory for commercial production

Company Advantages
1. The design of EcoPura bottle filler is a combination of various technologies. They are mainly automation, intelligence, sensing, computer science, and mechanical engineering technologies. Adopting an intelligent circuit design, the product has a self-check function
2. The product will remain stable throughout its lifetime. So people can enjoy its natural colors for years to come. The product can ensure a high filtration rate
3. The product can stand up with chemical treatment. It is able to withstand chemical sterilants such as formaldehyde, glutaraldehyde, and chlorine dioxide. The product generates little noise during operation
4. The product has no flaws or defects on its surface. The sintering process is conducted at more than 2000 degrees Fahrenheit to make the glaze smooth and even. Its overload protection function can effectively protect operators from harm

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura affordable bottle filler factory for commercial production-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3	0.33L-1.5L Height:150-330mm Dia: 50-115mm	2000-3000bph	1.5kw	SIEMENS
HSG16-12-6		3000-4500bph	1.8kw
HSG24-16-6		5000-6000bph	2.2kw
HSG24-18-8		7000-8000bph	2.2kw
HSG24-24-8		10000-12000bph	3.0kw
HSG32-32-12		15000-18000bph	5.5kw
HSG38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura affordable bottle filler factory for commercial production-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura affordable bottle filler factory for commercial production-3

EcoPura affordable bottle filler factory for commercial production-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura affordable bottle filler factory for commercial production-5

EcoPura affordable bottle filler factory for commercial production-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. We are a leader in the market of offering bottle filler .
2. Almost all technician talent for the industry of automatic liquid filling machine work in our Shenzhen EcoPura Water Equipment Co.,Ltd.
3. Our philosophy is: the basic prerequisites for the healthy growth of the company are not only satisfied clients but also satisfied employees.

u******n

automatic liquid filling machine Hard and strong, wear-resistant and dirt-resistant, easy to clean and take care of, just wipe gently with a towel or mop, and it will be as clean as new.

h******c

automatic liquid filling machine It is made with advanced manufacturing technology and fine processing technology. It is solid in texture, stable in structure, safe and reliable in use, and can bring you a different slimming experience.

a******l

The bottle mouth of automatic liquid filling machine adopts a tight screw neck design, which has a good sealing effect and is not prone to liquid leakage, so it can be used with confidence when you go out.

s******u

We insist on fine workmanship, and the bottling machine produced is thick and uniform in texture, good in gloss, delicate in hand without burrs, firm and firm, and has a long service life.

m******v

[企业简称] Insist on the selection of high-quality materials and adopt advanced manufacturing technology to produce automatic liquid filling machine. The manufactured products are excellent in workmanship, stable in performance and high in quality, and enjoy a high degree of recognition in the market.

b******n

This product is internationally renowned for its superior performance and long life. Its sizes and styles can be customized
