affordable automatic liquid filling machine water factory for commercial production

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine insists on the use of high-quality materials and advanced technology to manufacture bottling line. Besides, we strictly monitor and control the quality and cost in each production process. All this guarantees the product to have high quality and favorable price.bottling line's outstanding advantages are as follows.

Company Advantages
1. EcoPura automatic liquid filling machine is safe as it is made of high quality materials.
2. automatic liquid filling machine have strong resistance to bottling machine.
3. Due to its high accuracy levels, the product can improve production achievement whilst also reducing the time needed for quality control.
4. The product enables manufacturers free from the risk of staff shortages. It significantly helps reduce the number of needed workers for production.

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura affordable automatic liquid filling machine factory for commercial production-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
HSG24-24-18-8		7000-8000bph	2.2kw
HSG24-24-24-8		10000-12000bph	3.0kw
HSG32-32-32-12		15000-18000bph	5.5kw
HSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura affordable automatic liquid filling machine factory for commercial production-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura affordable automatic liquid filling machine factory for commercial production-3

EcoPura affordable automatic liquid filling machine factory for commercial production-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

EcoPura affordable automatic liquid filling machine factory for commercial production-5

EcoPura affordable automatic liquid filling machine factory for commercial production-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura affordable automatic liquid filling machine factory for commercial production-7

Company Features
1. Drawing from years of experience, Shenzhen EcoPura Water Equipment Co.,Ltd has been grown into one of the most powerful manufacturers in China. We are an expert in design, manufacture, and sales.
2. The factory has advanced machinery and equipment. Continued investment in these facilities is related to the adoption and dissemination of the latest technology, which is the key to increasing our productivity.
3. EcoPura Water Treatment Equipment & Bottling Machine serves customers, understand their needs, and strive to meet those needs. Call now! Shenzhen EcoPura Water Equipment Co.,Ltd will continue to improve the core competitiveness of our factory. Call now!

u******y

Shenzhen EcoPura Water Equipment Co.,Ltd has a modern factory building, and introduces advanced bottling machine production equipment, and bottling machine after the production is completed, it will be tested by the relevant national departments to meet the national quality standards, ensuring that it not only has high output, but also stable performance and high quality .

z******a

Shenzhen EcoPura Water Equipment Co.,Ltd After years of careful management, a set of scientific and rigorous production process has been established, and the quality is strictly controlled in all aspects of product design, production, quality inspection, and delivery. The automatic liquid filling machine produced is fine in workmanship and high in quality , Strong practicability.

a******v

bottling machine The workmanship is fine, the materials are exquisite, the design is scientific, the structure is reasonable, and before leaving the factory, there will be special quality inspection personnel to test, so the quality is guaranteed.

e******a

We pay great attention to product quality, adhere to the introduction of scientific production concepts, adopt professional production equipment and use advanced production technology to manufactureautomatic liquid filling machine, and have established a complete set of quality inspection procedures to strictly test each batch of products leaving the factory to ensure that all Products are in line with national quality inspection standards.

e******i

automatic liquid filling machine Carefully designed by professional designers, the design is scientific and reasonable, and selected high-quality raw materials are processed with advanced technology to make it of excellent quality and more durable.

y******a

This product is able to achieve maximum light output in a matter of seconds. being arranged in an orderly manner, its bulb can work simultaneously and provide full brightness in one second. Aluminum materials help it reduce maintenance costs
