low cost small liquid filling machine 4in1 manufacturer for commercial production

Company Advantages
1. The whole production of EcoPura water bottling plant is carried out based on the requirement of lean production. The product has a reliable electrical system, without any short circuit, or electric leakage occurring
2. This product has been widely used in the industry due to its excellent properties. Its overload protection function can effectively protect operators from harm
3. This product has a high yield. Once the design basic parameters and standard specifications are entered into the product, it can perform high-volume daily tasks from start to finish and provide flexible scalability. It has a robust design, supported by an aluminum plate

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura 4in1 small liquid filling machine manufacturer for commercial production-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
HSG24-24-18-8		7000-8000bph	2.2kw
HSG24-24-24-8		10000-12000bph	3.0kw
HSG32-32-32-12		15000-18000bph	5.5kw
HSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura 4in1 small liquid filling machine manufacturer for commercial production-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura 4in1 small liquid filling machine manufacturer for commercial production-3

EcoPura 4in1 small liquid filling machine manufacturer for commercial production-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

EcoPura 4in1 small liquid filling machine manufacturer for commercial production-5

EcoPura 4in1 small liquid filling machine manufacturer for commercial production-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura 4in1 small liquid filling machine manufacturer for commercial production-7

Company Features
1. Over the years, Shenzhen EcoPura Water Equipment Co.,Ltd has evolved from a traditional manufacturing company into a leader in the designing and manufacturing of water bottling plant .
2. We have set up a team to manage exports and distribution. With their years of experience in developing markets, they are able to manage well the distribution of our products around the world.
3. Our mission is to use our expertise in power conversion to increase our customers’ competitiveness and to contribute to reducing their environmental impact.

a******t

The surface of small liquid filling machine is specially treated with waterproof technology, which is resistant to dirt and easy to clean.

g******a

water bottling plant Exquisite material selection, exquisite workmanship, stable quality, excellent quality, smooth surface, solid and thick texture, safe and reliable quality.

o******b

small liquid filling machine The design is scientific and reasonable, and the structure is tight and compact. It adopts an intelligent operating system, which can make it easy to grasp the dynamics of water purification. It is easy to operate and easy to install. It is a practical and intelligent drinking water equipment product.

m******a

small liquid filling machine The materials are carefully selected, the materials are full, the workmanship is fine, and the quality is high. Even if it is used for a long time, it is not easy to deform and rust.

f******s

small liquid filling machine The structural design is reasonable, the assembly and disassembly are simple, and it has the advantages of small footprint, low cost, short production cycle, and recyclability. It has both aesthetics and practicability, and has a good product display function.

l******e

There is a wide of applications for small liquid filling machine which is very useful. The product is well-known for its good heat dissipation
