affordable bottle filler 3in1 factory for liquids

Product Comparison

Under the guidance of market, EcoPura Water Treatment Equipment & Bottling Machine constantly strives for innovation. water treatment equipment has reliable quality, stable performance, good design, and great practicality.water treatment equipment has the following advantages over other products in the same category.

Company Advantages
1. EcoPura bottling machine is professionally designed. It has been considered in many aspects including strength, stiffness, weight, cost, wear, safety, reliability, etc.
2. The product features high precision. The machines are equipped with control probes that allow the dimensions to be checked while the piece is still in the machine, thus avoiding repositioning that would decrease the required precision.
3. The product features enough durability. Its components such as padding, eyelets, upper surface are firmly sewn or glued together to be used for a long time.
4. Having this product definitely speeds up the production time. Because no thinking is needed by it, there is better repeatability and less human error.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc

EcoPura 3in1 bottle filler factory for liquids-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3	0.33L-1.5L Height:150-330mm Dia: 50-115mm	2000-3000bph	1.5kw	SIEMENS
HSG16-12-6		3000-4500bph	1.8kw
HSG24-16-6		5000-6000bph	2.2kw
HSG24-18-8		7000-8000bph	2.2kw
HSG24-24-8		10000-12000bph	3.0kw
HSG32-32-12		15000-18000bph	5.5kw
HSG38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura 3in1 bottle filler factory for liquids-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura 3in1 bottle filler factory for liquids-3

EcoPura 3in1 bottle filler factory for liquids-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems .ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch.ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura 3in1 bottle filler factory for liquids-5

EcoPura 3in1 bottle filler factory for liquids-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is a large-scale bottle filler manufacturer in China.
2. Always aim high in quality of small liquid filling machine.
3. Serving the overall strategy of automatic liquid filling machine to promote upgrading of EcoPura is the persistent goal. Get info! The establishment of a good brand image needs the efforts of each EcoPura employee. Get info!

FEATURE

1. This machine is belonged to semi-automatic piston platform type filling machine for viscosity.

2. Filling quantity and speed can be adjusted..

3. Easy to operate, with high accuracy, simple to maintain and clean.

4. Pneumatic parts: normally adopt Airtac brand, also can choose FESTO,

5. Can set manual or automatic mode.

6. With good structure, easy to removal & installation.

7. Material contact part with SUS316, meet GMP operational standard.

8. With excellent design, with platform and small structure to save installation space.

9. Be suitable for various products with small weight.

10. Seal parts with silicone rubber which with high anti-abrasion, anti-heat, anti-acid,

anti-corrosion function, with fluorine rubber which is high anti-abrasion, anti-resistance, anti-acid, and anti-corrosive.

APPLICATION

FM-SMT CrossQ Semi-auto Platform Paste Filling Machine mainly used for viscosity products, such as pesticide, medicine, toothpaste, foods(sesame paste, sweet paste, tomato sauce, peanut butter, chocolate jam, cream), chemical glass adhesive, lubricant and special industrial paste.

[ECHNICAL PARAMETER

Model	Filling Range	Accuracy	Filling Speed (pcs/min)	Air Supply ( L/min )	Power Supply	Dimension ( mm )	Weight
FM-SMT/100	10-100g	±0.5%	10-40	88	AC220V 50HZ	950x260x650	26kg
FM-SMT/250	30-250g		10-40	113		950x260x730	28kg
FM-SMT/500	100-500g		10-30	230		1030x260x775	31kg
FM-SMT/1000	200-1000g		10-25	335		1250x260x850	33kg
FM-SMT/5000	1000-5000g		5-15	415		1450x260x900	55kg

Above is standard data, different products and viscosity may effect above data.
