EcoPura Water Treatment Equipment & Bottling Machine carries out strict quality monitoring and cost control on each production link of water treatment equipment, from raw material purchase, production and processing and finished product delivery to packaging and transportation. This effectively ensures the product has better quality and more favorable price than other products in the industry.water treatment equipment's outstanding advantages are as follows.

Company Advantages
1. EcoPura filling system adopts the highest and strictest standards for the selection of raw materials.
2. mineral water bottle filling machine are expertly engineered to be of filling system .
3. Utilizing filling system system can prevent the accident of mineral water bottle filling machine from product development to package.

Product Detail

ECOPURA 5gallon bottle washing filling capping machine HSG600 with capacity 600bph.
A real Hygiene filling solution for your recycling use 5Gallon bottled water business with SIEMENS PLC Control and touch Screen control. All parts that come to contact with water are manufactured in Stainless steel 304 or 316L ,Equipped S.S304 Chemical tank for multistage rinsing

automatic mineral water bottle filling machine 5gallon manufacturer for industrial production-1

automatic mineral water bottle filling machine 5gallon manufacturer for industrial production-2

Bottles Sterilizing & Washing

Exclude the brusher pre-washing process for cleaning bottles inside & outside part, the pre-washed 5gallon bottles feed into the 3-in-1 washing filling capping unit which Designed Multistage high-pressure inner washing Process include Hot Alkaline washing, disinfection water washing, Dripping ,Ozonated pure water cleaning for ensuring the recycled bottles 100% clean & health, the washing system is controlled by pumping though cleaning tank and the ejecting nozzles on the bottle carrier to spraying the inner wall of the bottles by high pressure water, after finishing the washing process, the bottles will discharge though reverse turn-over mechanize and transported to the filling Part for full filling as designated volume and finally capping, discharge out the 3-in-1 by conveyor to next step

Caps Loading & washing

The Caps elevator doses the caps into the caps unscrambler then delivery through caps chute to enter into caps washing tunnel, finished clean caps feed following the chute transferring to capping position on capping machine .Design for online 5Gallon caps cleaning & Sterilizing by multistage washing process -detergent washing & purified water washing,

automatic mineral water bottle filling machine 5gallon manufacturer for industrial production-3

automatic mineral water bottle filling machine 5gallon manufacturer for industrial production-4

Rotary Filling & Capping

Clean bottles are discharged out of the rinse by conveyor to feed the filler. After entering the filler, bottles are retained by bottom supporting plates, which are actuated by bottle supporting mechanism to raise them to engage with filling valves. Filling valves are opened by bottle presence signals. After finishing filling, valves are closed by valve closing mechanism to further stop venting to complete the filling process.

Product Solution

A turnkey solution for 5Gallon bottling line

♦ 1.Automatic bottle decapper
♦ 2.Automatic inside & outside brusher washer
♦ 3.Automatic bottle feeder -Multistage high-pressure washing unit
♦ 4.Linear or Rotary filler & capper
♦ 5.Automatic Capsules Labeling shrinking
♦ 6.Light Inspection
♦ 7.Thin film (bag) Packing
♦ 8.Palletizer

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is the professional supplier of the international high-quality mineral water bottle filling machine provider.
2. Strong technical force and excellent pre-sales service is the driving force of Shenzhen EcoPura Water Equipment Co.,Ltd's development.
3. The vision of EcoPura is to become a well-known brand in the world. Call now! With efforts to improve the quality of service and water filling equipment , EcoPura aims to become a more popular brand. Call now! EcoPura consistently sets customer first as the business philosophy. Call now! We are committed to becoming a standard company in water bottling equipment industry. Call now!
