Product Information of 3in1 water bottling plant trade partner for liquids EcoPura
Product Details
In the production, EcoPura Water Treatment Equipment & Bottling Machine believes that detail determines result and quality creates brand. This is the reason that we strive for excellence in every product detail.Well-chosen in material, fine in workmanship, excellent in quality and favorable in price, EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment is highly competitive in the domestic and foreign markets.
Product Comparison
Under the guidance of market, EcoPura Water Treatment Equipment & Bottling Machine constantly strives for innovation. bottle filling machine has reliable quality, stable performance, good design, and great practicality.EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine has the following advantages over products in the same category.
  • v s
Company Advantages
1. bottle filler exceed other similar products with its water bottling plant design.
2. bottle filler is an water bottling plant for this purpose due to its characteristics of bottling machine.
3. Advanced equipment in EcoPura ensure the bulk production of bottle filler to raise the efficiency.
Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral ,still water and other liquids etc


3in1 water bottling plant trade partner for liquids EcoPura-1

Product Specification

Model

Bottle Spec

Capacity Cal@500ML

Power

PLC & HMI

HSG24-24-16-6

0.33L-1.5L
Height:150-330mm
Dia: 50-115mm

5000-6000bph

2.2kw

SIEMENS

HSG24-24-18-8

7000-8000bph

2.2kw

HSG24-24-24-8

10000-12000bph

3.0kw

HSG32-32-32-12

15000-18000bph

5.5kw

HSG38-38-38-14

18000-20000bph

7.5kw

EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

3in1 water bottling plant trade partner for liquids EcoPura-2

High quality & Strict Hygiene
Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

3in1 water bottling plant trade partner for liquids EcoPura-3

3in1 water bottling plant trade partner for liquids EcoPura-4

Ozonated water Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

Filling Part
Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety -Contact-free filling and optimized machine design. High filling accuracy -Use of flow meters and infinitely variable flow speeds. High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems. ECOPURA standard Machines are suitable for CIP

3in1 water bottling plant trade partner for liquids EcoPura-5

3in1 water bottling plant trade partner for liquids EcoPura-6

Capping Part
The capper is most precise part ensuring the machine to run credibility and product quality. The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304. Pick station with adjustable height. Torque and spring force of the capping head are adjustable. Flushable cap retainer. Motorised height adjustment of the capper top part with bottle selection feature
Caps online Sterilization
ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

3in1 water bottling plant trade partner for liquids EcoPura-7


Company Features
1. Owing to the contribution of our well-trained water bottling plant , EcoPura has received more popularity.
2. bottle filler is the offspring of the highest technology and advanced facilities.
3. Shenzhen EcoPura Water Equipment Co.,Ltd emphasize the oversight and analysis to completely improve brand awareness, social reputation and loyalty. Inquire now! As a major employer, we recognize that we have a duty to contribute to the wider economy, creating jobs, using local suppliers and supporting our clients in tackling local socio-economic issues. Inquire now! EcoPura Water Treatment Equipment & Bottling Machine strives to provide quality service for every customer. Inquire now! EcoPura establishes a sensible management system for the long-term development of its customers. Inquire now!
COMARK MACHINE
Auxiliary Equipment
Ro water treatment plant.

•Stainless steel high pressure film shell

•All kinds of capacity indicator, pressure indicator, electricity magnetic valve, balance device and pipe valve system

•Online type pressure auto self-protection device

•Online type electricity indicator (with stable compensation)

•System safe protecting and alarm system

•System frame

blow moulding machine.

Blow molding system.

Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.

Automatic labeling machine.

1/Heat shrink sleeve labeling machine

2/OPP Hot melt labeling machine

3/PVC label stick labeling machine

It adopts double driving structure which is a new and advanced driving device for the thermal shrink sleeve machine, that is, four-wheel driving, self-centering and balanced pressure of four wheels. It can achieve the good effect of transmission of labels smoothly, stably and rapidly.
auto warpping packaging machine.

1/PE film shrink wrapping machine

2/Half-tray shrink wrapping machine

3/Carton box packaging machine



It adopts the photoelectric sensor to detect online, gather signals which are controlled by PLC, and adopts piston as executable element, to realize product conveying, combination, film wrapping, cutting, heat& shrink, cool and finally get the finished product.
