new mineral water filling machine filler producer for factory

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine achieves the organic combination of culture, sci-tech, and talents by taking business reputation as the guarantee, by taking service as the method and taking benefit as the goal. We are dedicated to providing customers with excellent, thoughtful and efficient services.

Company Advantages
1. The design of EcoPura mineral water filling machine is ingenious. The color assortment, bathroom style, space, positioned place of the product have been taken into consideration by the interior designers.
2. This product has great strength. It has the ability to withstand mechanical shocks from suddenly applied forces or an abrupt change in motion produced by handling, transportation or field operation.
3. This product has good strength. Various types of load such as steady loads (dead loads and live loads) and variable loads (shock loads and impact loads) have been considered in designing its structure.
4. The product adds a sense of contemporary and elegant style to any kitchen and dining table, and it's perfect to use in any formal or casual dining gatherings.

Product Detail

ECOPURA 3-in-1 PET 3L-10L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral, still water and other liquids etc

new mineral water filling machine filler producer for factory-1

Product Parameter

Model	Bottle Spec	Capacity Cal@5L	Power	PLC & HMI
HSG10-10-5	3L-10L	1200-1500bph	2.2kw	SIEMENS
HSG12-12-5		1500-2000bph	3.0kw
HSG14-14-5		2000-2500bph	4.0kw
HSG16-16-5		2500-3000bph	5.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

new mineral water filling machine filler producer for factory-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination
The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

new mineral water filling machine filler producer for factory-3

new mineral water filling machine filler producer for factory-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.
Bottom-holding position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge.
Microbiological safety -Contact-free filling and optimized machine design
High filling accuracy -Use of flow meters and infinitely variable flow speeds
High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems
ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutchends the capping process. All main parts made of stainless steel AISI304 . Pick station with adjustable height Torque and spring force of the capping head are adjustable . Flushable cap retainer . Motorised height adjustment of the capper top part with bottle selection feature

new mineral water filling machine filler producer for factory-5

new mineral water filling machine filler producer for factory-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Since the foundation, Shenzhen EcoPura Water Equipment Co.,Ltd has built a reputation in the field of developing and manufacturing of fill line .
2. The factory has been equipped with many state-of-the-art manufacturing machines. They are highly effective in improving productivity with the least labor intervention, which helps save overall production costs.
3. Creating the first-class mineral water filling machine enterprise is our mutual goal for all staff in EcoPura. Get an offer! The vision of EcoPura is water bottle filling machine which support our company to be the prominent manufacturer in the future. Get an offer! Improving the quality with all round service is the concept for EcoPura to develop. Get an offer! We can provide customers with product commissioning and technical training services. Get an offer!
