hot sale liquid filler filler overseas trader for distribution

Application Scope

EcoPura Water Treatment Equipment & Bottling Machine's bottle filling machine is widely applicable in the Manufacturing Machinery industry.EcoPura Water Treatment Equipment & Bottling Machine insists on providing customers with comprehensive solutions based on their actual needs, so as to help them achieve long-term success.

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine pays attention to product quality and service. We have a specific customer service department to provide comprehensive and thoughtful services. We can provide the latest product information and solve customers' problems.

Company Advantages
1. EcoPura water filter plant machine price has been strictly evaluated. The assessments include finite element stress analysis of all components, fatigue analysis, load increase analysis, etc.
2. The product features high dimension accuracy. During the inspection stage, its sizes have been scrutinized and tested by different measuring tools to make sure zero dimension error.
3. The product is reliable in operation. It is not prone to cause some dangerous effects such as electric current, and sudden stop.
4. This product is reliable in property and reputably appraised by customers in the industry.

Product Detail

ECOPURA 3-in-1 PET 3L-10L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral, still water and other liquids etc

hot sale liquid filler filler overseas trader for distribution-1

Product Parameter

Model	Bottle Spec	Capacity Cal@5L	Power	PLC & HMI
HSG10-10-5	3L-10L	1200-1500bph	2.2kw	SIEMENS
HSG12-12-5		1500-2000bph	3.0kw
HSG14-14-5		2000-2500bph	4.0kw
HSG16-16-5		2500-3000bph	5.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

hot sale liquid filler filler overseas trader for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination
The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

hot sale liquid filler filler overseas trader for distribution-3

hot sale liquid filler filler overseas trader for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.
Bottom-holding position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge.
Microbiological safety -Contact-free filling and optimized machine design
High filling accuracy -Use of flow meters and infinitely variable flow speeds
High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems
ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutchends the capping process. All main parts made of stainless steel AISI304 . Pick station with adjustable height Torque and spring force of the capping head are adjustable . Flushable cap retainer . Motorised height adjustment of the capper top part with bottle selection feature

hot sale liquid filler filler overseas trader for distribution-5

hot sale liquid filler filler overseas trader for distribution-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is a diversified Chinese liquid filler company.
2. With strong R&D capabilities, Shenzhen EcoPura Water Equipment Co.,Ltd has invested heavily in the development of water bottle filling machine .
3. It is Shenzhen EcoPura Water Equipment Co.,Ltd's mission to significantly shorten the customer development cycle. Get quote! Shenzhen EcoPura Water Equipment Co.,Ltd holds the business idea of water filter plant machine price and hope to succeed together with our customers. Get quote! Shenzhen EcoPura Water Equipment Co.,Ltd is committed to providing users with ultimate experience of products and services to make life more colorful. Get quote!

Inform

Our main business/products:

1.Aluminum foil induction sealing machine

Including manual sealing machine for small business/home business, tabletop continuous sealing machine medium factory, automatic sealing machine for production line. Our sealers are with high sealing quality which are widely used to seal PET bottles, PP bottles, PVC bottles, PE bottles, HDPE bottles, plastic bottles, glass bottles, etc in cosmetic, drinks, chemical, medical, food industry etc

2. liquid/paste filling machine

Such as gear pump liquid filling machine, pneumatic semi automatic paste filling machine, automatic filling machine. They are suitable to fill water, beverage, oil, ink, lotion, shampoo, sauce, jam, gel, cream, etc in the field of cosmetic, drinks, chemical, medical, food, etc

3.self adhesive labeling machine

like semi automatic labeling machine and full automatic labeling machine which can label all round objects such as bottles, jars, cans, etc and all plane surfaces such as box, bottles, cards, etc. in cosmetic, drinks, chemical, medical, food industry etc

4. plastic lids capping machine

Including semi automatic capping machine and full automatic labeling machine which can highly improve the productivity and product quality in capping bottles, jars, atomizers etc in the area of cosmetic, drinks, chemical, medical, food etc.

Video of this machine is ready to send .

Any requirements or questions, please feel free to send an inquiry or leave a message to let us know and get more information about the machines.
