high quality juice filling equipment machine international market for upgrade industries

Application Scope

The water treatment equipment of EcoPura Water Treatment Equipment & Bottling Machine is applicable in the following scenes.EcoPura Water Treatment Equipment & Bottling Machine always pays attention to customers. According customers' actual needs, we could customize comprehensive and professional solutions for them.

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine has professional production workshops and great production technology. bottling line we produce, in line with the national quality inspection standards, has reasonable structure, stable performance, good safety, and high reliability. It is also available in a wide range of types and specifications. Customers' diverse needs can be fully fulfilled.EcoPura Water Treatment Equipment & Bottling Machine's bottling line is produced in strict accordance with standards. We make ensure that the products have more advantages over similar products in the following aspects.

Company Advantages
1. EcoPura juice filling equipment goes through professional design. It is created by experts who have vast knowledge and experience in the following standards: IP Protection, UL, CE, environment and explosive Std, CSA, FM, etc.
2. The product has been accredited by authoritative third parties in all aspects, such as performance, durability, and reliability.
3. This product can perform a large number of risky work in a risky industrial production environment. Therefore, workers are not easily injured or overworked.

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

high quality juice filling equipment machine international market for upgrade industries-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
RHSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
RHSG24-24-18-8		7000-8000bph	2.2kw
RHSG24-24-24-8		10000-12000bph	2.0kw
RHSG32-32-32-12		15000-18000bph	5.5kw
RHSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

high quality juice filling equipment machine international market for upgrade industries-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

high quality juice filling equipment machine international market for upgrade industries-3

high quality juice filling equipment machine international market for upgrade industries-4

Ozonated Water Washing Part

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

high quality juice filling equipment machine international market for upgrade industries-5

high quality juice filling equipment machine international market for upgrade industries-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish.As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

high quality juice filling equipment machine international market for upgrade industries-7

Company Features
1. With rich industry experience, Shenzhen EcoPura Water Equipment Co.,Ltd is deeply trusted by customers all over the world.
2. Innovation is EcoPura Water Treatment Equipment & Bottling Machine's approach to R&D and operations.
3. By providing highly cost-effective products, Shenzhen EcoPura Water Equipment Co.,Ltd brings a high-quality life to customers. Get more info! EcoPura is devoted to providing customers with high quality juice filling equipment. Get more info!

r******f

Shenzhen EcoPura Water Equipment Co.,Ltd has a modern factory building, and introduces advanced juice filling equipment production equipment, and juice filling equipment after the production is completed, it will be tested by the relevant national departments to meet the national quality standards, ensuring that it not only has high output, but also stable performance and high quality .

q******k

Shenzhen EcoPura Water Equipment Co.,Ltd After years of careful management, a set of scientific and rigorous production process has been established, and the quality is strictly controlled in all aspects of product design, production, quality inspection, and delivery. The juice filling equipment produced is fine in workmanship and high in quality , Strong practicability.

a******p

tea filling machine The workmanship is fine, the materials are exquisite, the design is scientific, the structure is reasonable, and before leaving the factory, there will be special quality inspection personnel to test, so the quality is guaranteed.

k******d

We pay great attention to product quality, adhere to the introduction of scientific production concepts, adopt professional production equipment and use advanced production technology to manufacturetea filling machine, and have established a complete set of quality inspection procedures to strictly test each batch of products leaving the factory to ensure that all Products are in line with national quality inspection standards.

d******c

juice filling equipment Carefully designed by professional designers, the design is scientific and reasonable, and selected high-quality raw materials are processed with advanced technology to make it of excellent quality and more durable.

f******s

This product is able to achieve maximum light output in a matter of seconds. being arranged in an orderly manner, its bulb can work simultaneously and provide full brightness in one second. It helps minimize downtime and maximize operational efficiency
