high quality juice bottling machine 3in1 more buying choices for distribution

Company Advantages
1. The design of EcoPura juice bottle filling machine is scientific. It is the application of mathematics, kinematics, mechanics of materials, mechanical technology of metals, etc. Equipped with a safety system, the product can detect the faults
2. This is a favorable point for this product as it does not have any internal process so the noise decreases to zero. The product is easy to clean with no blind corners
3. High dimensional accuracy is the prominent point of the product. Advanced cutting tools and techniques are applied to ensure its dimension precision. The product features a high degree of automation

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

high quality juice bottling machine 3in1 more buying choices for distribution-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

high quality juice bottling machine 3in1 more buying choices for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

high quality juice bottling machine 3in1 more buying choices for distribution-3

high quality juice bottling machine 3in1 more buying choices for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

high quality juice bottling machine 3in1 more buying choices for distribution-5

high quality juice bottling machine 3in1 more buying choices for distribution-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. With its complete juice bottling machine industry chain, EcoPura has gained more fame since its establishment. Shenzhen EcoPura Water Equipment Co.,Ltd has professional machines and experience in the field.
2. The competitive machines make Shenzhen EcoPura Water Equipment Co.,Ltd produce high-quality juice filling equipment.
3. EcoPura has always adhered to independent innovation technology and established its own core business. We always keep technological innovation in mind and realize the long-term development of juice bottle filling machine . Inquire!

o******k

EcoPura juice bottling machine is well designed. Its detailed design includes mechanical design, structural design, electrical control design, instrument panel design, etc.

z******c

The manufacture of EcoPura juice filling equipment includes the specific design of the polymer optical component, assembly, concept and prototype testing through to mass production with multiple injection molding processes, optoelectronic assembly, and packing.

r******o

Quality tests of EcoPura juice filling equipment will be conducted rigorously complying with the requirements in the phone accessories industry. It has a series of quality tests including pressure test, high/low-temperature test, strength test, etc.

r******b

Before production, the materials and components of EcoPura juice bottle filling machine have to go through inspections. They must be verified by the QC team to ensure its maximum electrical safety.

g******n

EcoPura juice filling equipment is made with suitable materials. The designer determines the material according to the goods. For example, if the displayed goods are heavy, the better choice is wood/wire/plastic material.

p******p

This high-quality juice bottle filling machine is constructed with well-chosen materials and elaborate workmanship. It is a safe and eco-friendly product with high sturdiness and long-lasting durability. It is easy to assemble and disassemble. It sells well and enjoys wide acclaim in the domestic and foreign markets.
