ISO9001 certified wine filling machine wine factory for market

Product Details

EcoPura Water Treatment Equipment & Bottling Machine pays great attention to product quality and strives for perfection in every detail of products. This enables us to create fine products.EcoPura Water Treatment Equipment & Bottling Machine's bottling line is commonly praised in the market due to good materials, fine workmanship, reliable quality, and favorable price.

Company Advantages
1. EcoPura wine filter machine is manufactured under the vigilance of our diligent professionals as per production norms using premium quality materials.
2. The product has the advantage of a robust machine structure. Constructed with a rugged metal frame, it is highly resistant to impacts and vibrations.
3. When I bought this product, I think it can last for a long time. So far, I couldn't find any failure happened on my machine. - - Said one of our customers.
4. People will find it is extremely easy to hold up. All they need to do is put it in the desired area, peg it down, and inflated it with a floor pump.

Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine

EcoPura wine wine filling machine factory for market-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3G	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-3000bph	1.5kw	SIEMENS
HSG16-12-6G		3000-4500bph	1.8kw
HSG24-16-6G		5000-6000bph	2.2kw
HSG24-18-8G		7000-8000bph	2.2kw
HSG24-24-8G		10000-12000bph	3.0kw
HSG32-32-12G		15000-18000bph	5.5kw
HSG38-38-14G		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura wine wine filling machine factory for market-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura wine wine filling machine factory for market-3

EcoPura wine wine filling machine factory for market-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part

After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

EcoPura wine wine filling machine factory for market-5

EcoPura wine wine filling machine factory for market-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. As an experienced manufacturer and supplier of wine filter machine , Shenzhen EcoPura Water Equipment Co.,Ltd has been one of the preferred choices in the market.
2. By strengthening the technological innovation capability, Shenzhen EcoPura Water Equipment Co.,Ltd has played a supporting role in the industry of wine filling machine .
3. We pledge to put both business success and environment protection as our priority. We assume social responsibility during production to reduce carbon footprint as much as possible. We strive to promote our sustainability program by working together with our customers and suppliers and fostering a company-wide culture of sustainability.

l******w

Shenzhen EcoPura Water Equipment Co.,Ltd has a modern factory building, and introduces advanced wine filter machine production equipment, and wine filter machine after the production is completed, it will be tested by the relevant national departments to meet the national quality standards, ensuring that it not only has high output, but also stable performance and high quality .

t******a

Shenzhen EcoPura Water Equipment Co.,Ltd After years of careful management, a set of scientific and rigorous production process has been established, and the quality is strictly controlled in all aspects of product design, production, quality inspection, and delivery. The wine filter machine produced is fine in workmanship and high in quality , Strong practicability.

p******l

wine filter machine The workmanship is fine, the materials are exquisite, the design is scientific, the structure is reasonable, and before leaving the factory, there will be special quality inspection personnel to test, so the quality is guaranteed.

n******f

We pay great attention to product quality, adhere to the introduction of scientific production concepts, adopt professional production equipment and use advanced production technology to manufacturewine filter machine, and have established a complete set of quality inspection procedures to strictly test each batch of products leaving the factory to ensure that all Products are in line with national quality inspection standards.

h******s

wine filter machine Carefully designed by professional designers, the design is scientific and reasonable, and selected high-quality raw materials are processed with advanced technology to make it of excellent quality and more durable.

w******u

This product is able to achieve maximum light output in a matter of seconds. being arranged in an orderly manner, its bulb can work simultaneously and provide full brightness in one second. It excellently supports cargo/passenger loading operations
