ISO9001 certified wine bottling machine wine factory for market

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine can provide high-quality and efficient management consulting service for customers at any time.

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine carries out strict quality monitoring and cost control on each production link of bottle filling machine, from raw material purchase, production and processing and finished product delivery to packaging and transportation. This effectively ensures the product has better quality and more favorable price than other products in the industry.bottle filling machine has the following advantages over other products in the same category.

Company Advantages
1. The production of EcoPura wine filler involves several stages. These stages include procurement of raw materials, welding and fabricating of the base or frame, machining of component parts, painting, and specialty finishing.
2. The product is able to yield the best results in the shortest time. It can perform tasks at a high speed while maintaining its consistency.
3. Shenzhen EcoPura Water Equipment Co.,Ltd's wine bottling machine is SGS compliant.
4. The increasing popularity of EcoPura also shows the high customer satisfication.

Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine

EcoPura wine wine bottling machine factory for market-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3G	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-3000bph	1.5kw	SIEMENS
HSG16-12-6G		3000-4500bph	1.8kw
HSG24-16-6G		5000-6000bph	2.2kw
HSG24-18-8G		7000-8000bph	2.2kw
HSG24-24-8G		10000-12000bph	3.0kw
HSG32-32-12G		15000-18000bph	5.5kw
HSG38-38-14G		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura wine wine bottling machine factory for market-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura wine wine bottling machine factory for market-3

EcoPura wine wine bottling machine factory for market-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part

After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

EcoPura wine wine bottling machine factory for market-5

EcoPura wine wine bottling machine factory for market-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is an R&D company with many years of experiences of researching and developing new wine bottling machine products.
2. Our factory delivers standardized production which is yielded by well-trained and highly motivated employees in combination with the most modern and eco-friendly machinery.
3. We aim to help clients succeed. We'll work hard to create value for customers, such as helping cut production costs or improving product quality. We are doubling our effort in gearing toward green manufacturing. We streamline the production process that emphasizes the reduction of waste and less pollution.

w******i

EcoPura wine bottling machine is the outcome of the crystallization of human wisdom. It is developed adopting the knowledge of ergonomics with the combination of the features of different mobile phones. The product has a reliable electrical system, without any short circuit, or electric leakage occurring

f******u

EcoPura wine filler is an inter infiltration result of various technologies. It is developed by the R&D team who adopts the mechanical technique, detection and sensing technology, automatic control technology, and servo drive technology. The product is widely used for commercial applications

z******m

EcoPura wine bottling machine is tested to guarantee its safety. After it is completed, it will be placed in the electromagnetic field where features strong current and high voltage to check its stability and reliability. Its parts are all made of CNC machines, which features high accuracy

e******l

EcoPura wine filler complies with energy efficiency standards. It is proven to be compatible in the USA, the EU, and China in terms of minimum energy performance standards (MEPS) and class-average standards. The product generates little noise during operation

k******f

EcoPura wine bottling machine is of flexible design. It is completely customizable on everything from the shape and size to the wrap and messaging. The product has been certified under UL and CE

l******z

The product has been audited and certified to be compliant with the strictest quality requirement. The product is equipped with a high-efficiency operation system
