factory directly supply wine bottling equipment wine trader for market

Company Advantages
1. EcoPura wine bottling equipment is developed by the R&D team complying with the philosophy of ergonomics. The team strives to keep up with the needs of the stores' counter locations and layout. Its overload protection function can effectively protect operators from harm
2. The product has significant economic benefits and a good application prospect. Its parts are all made of CNC machines, which features high accuracy
3. In order to meet customers' expectations and industry standards, products must pass strict quality inspection before leaving the factory. The dimension of this product can be customized according to needs

Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine

EcoPura wine wine bottling equipment trader for market-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3G	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-3000bph	1.5kw	SIEMENS
HSG16-12-6G		3000-4500bph	1.8kw
HSG24-16-6G		5000-6000bph	2.2kw
HSG24-18-8G		7000-8000bph	2.2kw
HSG24-24-8G		10000-12000bph	3.0kw
HSG32-32-12G		15000-18000bph	5.5kw
HSG38-38-14G		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura wine wine bottling equipment trader for market-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura wine wine bottling equipment trader for market-3

EcoPura wine wine bottling equipment trader for market-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part

After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

EcoPura wine wine bottling equipment trader for market-5

EcoPura wine wine bottling equipment trader for market-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. With comprehensive experience in manufacturing wine bottling line , Shenzhen EcoPura Water Equipment Co.,Ltd has been popularly accepted in the domestic and international market. Shenzhen EcoPura Water Equipment Co.,Ltd has outstanding features in scientific research and development.
2. As a manufacturer of wine filter machine , Shenzhen EcoPura Water Equipment Co.,Ltd is a leading technology enterprise.
3. Our high-quality products and professional expertise have earned the support of customers from domestic and overseas markets. We have established strong and stable business relationships with those partners for years. Shenzhen EcoPura Water Equipment Co.,Ltd strives to serve the best interests of our customers. Welcome to visit our factory!

t******d

EcoPura wine bottling equipment is under the real-time control of the R&D team. The team will carry out a routine sampling and analysis of the raw materials so as to acquire information necessary for the economic appraisal of ores and concentrates.

w******i

EcoPura wine bottling equipment is produced under advanced equipment. It will be processed by fastness to washing tester, steamer and washer, as well as vacuum cleaning equipment designed for textile.

v******c

EcoPura wine bottling equipment is under constant control in terms of health, safety, and environmental protection standards, as evidenced by the CE certificate issued.

u******v

The quality control of EcoPura wine bottling line is conducted rigorously. It is tested in terms of its air circulation, surface treatment, as well as the most important part, thermal dissipation performance.

g******v

All EcoPura wine filter machine are manufactured in compliance with rubber and plastic industry standards and are tested for quality conformance in the laboratory.

g******s

The product features stable performance. The proportions of the various raw materials are carefully mixed together to achieve consistent properties.
