low moq wine bottle filler wine manufacturer for industrial production

Application Scope

EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment can be used in different fields.EcoPura Water Treatment Equipment & Bottling Machine could customize comprehensive and efficient solutions according to customers' different needs.

Company Advantages
1. The manufacture of EcoPura wine filler is the application of various basic mechanical parts. They include gears, bearings, fasteners, springs, seals, couplings, and so forth.
2. It is breathable. The structure of its comfort layer and the support layer are typically open, effectively creating a matrix through which air can move.
3. This product has strong wear and tear resistance. Its surface is treated with the anti-scratch technique, which makes it withstand heavy use.
4. Shenzhen EcoPura Water Equipment Co.,Ltd has accumulated abundant capital and a number of customers and a steady business platform.
5. The product has an increasing user group.

Product Detail

ECOPURA 3-in-1 Glass 0.3L-1.5L HSG-G series monobloc equipped with overflow filler nozzles designated for filling wine or Sparking wine

EcoPura wine wine bottle filler manufacturer for industrial production-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
HSG8-8-3G	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-3000bph	1.5kw	SIEMENS
HSG16-12-6G		3000-4500bph	1.8kw
HSG24-16-6G		5000-6000bph	2.2kw
HSG24-18-8G		7000-8000bph	2.2kw
HSG24-24-8G		10000-12000bph	3.0kw
HSG32-32-12G		15000-18000bph	5.5kw
HSG38-38-14G		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura wine wine bottle filler manufacturer for industrial production-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura wine wine bottle filler manufacturer for industrial production-3

EcoPura wine wine bottle filler manufacturer for industrial production-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. The lift cylinder presses the bottle on to the filling valve where it is pre-evacuated several times. With non-carbonated beverages, the filling valve opens due to a movement of the control cylinder. With carbonated beverages, the bottle is pressurised and the valve opens as soon as the bottle and the ring bowl have the same pressure. At both of the filling processes, the liquid runs through a spreader along the bottle wall. The valve closes as soon as the bottle is entirely filled. The correction channel opens and the excessive fill quantity is displaced from the bottle to the end of the vent tube. With carbonated beverages, a snifting phase is performed in order to reduce the pressure in the bottle head space. Non- carbonated beverages can be removed from the filling valve right after filling is completed.

Aluminum Roll-On Capping Part

After they have been sorted according to their positions in the sorter, the caps are fed to the capper via an open chute. A towing shoe positions the caps, which are then directly picked up by the bottle. If a cap is missing, a safety plunger prevents contact between the rollers and the bottle neck finish. Depending on the cap type, a “fixed” or a deep-drawing plunger is used for press-on and shaping. The thread is rolled out via moveable arms, and if necessary, the tamper-evident band is flanged. The lateral pressure can be easily readjusted with adjusting screws.

EcoPura wine wine bottle filler manufacturer for industrial production-5

EcoPura wine wine bottle filler manufacturer for industrial production-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. The name EcoPura represents a unique Chinese-style wine bottle filler brand.
2. Shenzhen EcoPura Water Equipment Co.,Ltd has a perfect quality assurance system.
3. Our business philosophy is to deliver delight to our customers. We will try to provide effective solutions and cost benefits that are of mutual benefit to our company and our customers. We achieve sustainable development by reducing production waste. We have diverted our manufacturing and post-consumer waste solutions from landfill and waste valorization by incineration to higher value beneficial uses like recycling and upcycling.

g******v

The quality of EcoPura wine filler complies with the performance requirements for residential and nonresidential furniture. It has passed the aging, impact, vibration, stain, and structural stability testings.

b******r

In terms of surface finishes, EcoPura wine filler provide all possible options. The surface treatment is available in a variety of ways.

k******c

The manufacturing process of EcoPura wine filler is very complex. As long as a detail is missed in the structure, the mattress may not provide the required level of comfort.

i******j

EcoPura wine bottle filler is carefully created. Its design sets out with a desired aesthetic in mind. The function is catered to as a secondary factor.

p******s

EcoPura wine filler must undergo a quality control process. This includes checking the color fastness of the fabric, color correction, and the security of the attachment.

b******c

This product does not have the electric leakage problems. It is made of quality insulation materials and embedded with an insulation protection system to prevent electric danger.
