unbeatable price water bottle filling machine machine international trader for distribution

Application Scope

water treatment equipment has a wide range of applications.With a focus on customers, EcoPura Water Treatment Equipment & Bottling Machine analyzes problems from the perspective of customers and provides comprehensive, professional and excellent solutions.

Company Advantages
1. water bottle filling machine outshine other similar products due to its water bottling machine prices materials.
2. The product features an easy operation. It has a relatively simple operating system combining a powerful processing flow and provides simple operation instruction.
3. This product has many advantages and huge economic benefits, and has gradually developed into a trend in the industry.
4. The product is widely used in various industries.

Product Detail

ECOPURA 3-in-1 PET 3L-10L HSG-series monobloc equipped with overflow filler nozzles designated for filling non-carbonated beverages such as pure or mineral, still water and other liquids etc

EcoPura unbeatable price water bottle filling machine international trader for distribution-1

Product Parameter

Model	Bottle Spec	Capacity Cal@5L	Power	PLC & HMI
HSG10-10-5	3L-10L	1200-1500bph	2.2kw	SIEMENS
HSG12-12-5		1500-2000bph	3.0kw
HSG14-14-5		2000-2500bph	4.0kw
HSG16-16-5		2500-3000bph	5.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura unbeatable price water bottle filling machine international trader for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination
The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura unbeatable price water bottle filling machine international trader for distribution-3

EcoPura unbeatable price water bottle filling machine international trader for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.
Bottom-holding position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge.
Microbiological safety -Contact-free filling and optimized machine design
High filling accuracy -Use of flow meters and infinitely variable flow speeds
High availability -Top efficiency thanks to the combination with ECOPURA cap feed systems
ECOPURA standard Machines are suitable for CIP

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutchends the capping process. All main parts made of stainless steel AISI304 . Pick station with adjustable height Torque and spring force of the capping head are adjustable . Flushable cap retainer . Motorised height adjustment of the capper top part with bottle selection feature

EcoPura unbeatable price water bottle filling machine international trader for distribution-5

EcoPura unbeatable price water bottle filling machine international trader for distribution-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Since our establishment, Shenzhen EcoPura Water Equipment Co.,Ltd has grown into a competitive water bottling machine prices manufacturer through technical expertise.
2. The factory is located in an advantageous place where it is the combination part of the new urban area and old urban area and is not far away from ports and major highways. This location benefits not the factory but also customers.
3. Shenzhen EcoPura Water Equipment Co.,Ltd contributes to the society with the collective strength of the company. Contact! EcoPura always sticks to the principle that quality is above everything. Contact! The guidance of water filter plant machine price will lead EcoPura to move forward in a right way. Contact!

p******m

The design of EcoPura water bottle filling machine involves several factors. These factors include part tolerances, size limitations, materials selection, mechanical analysis, function realization, etc. It is widely used in the chemical industry, metal & mining industry, etc

w******o

The workmanship of EcoPura water bottling machine prices requires particular skills of machinists. It has to be welded, stamped, and brazed by professional workers, and its parts are put together and fastened by hands during assembly. Customized catalogs and brochures related to the product are available

m******l

EcoPura water filter plant machine price is manufactured in line with industrial standards. Its plug, electric cords, and socket are made complying with the local electricity supply system. It won't be affected by any factors like high temperature, pressure, density, viscosity, etc

m******e

EcoPura water bottling machine prices is manufactured by taking an array of regulatory compliance into considerations, including electrical safety, electromagnetic compatibility (EMC) and the chemical composition of materials. Customized catalogs and brochures related to the product are available

j******s

EcoPura water filter plant machine price meets electrical international standards. They generally include IEC 60038 (IEC standard voltages) and IEC60076 (Power transformers). Customized catalogs and brochures related to the product are available

i******n

This product has certain air permeability. It provides a tunnel for the skin to exchange air with the outside world. In the meantime, it contributes to the divergence of human heat. This product has certain air permeability. It provides a tunnel for the skin to exchange air with the outside world. In the meantime, it contributes to the divergence of human heat. It has a clear and user-friendly display screen
