strict inspection water treatment system water solution expert for the global market

Product Details

With the dedication to pursue excellence, EcoPura Water Treatment Equipment & Bottling Machine strives for perfection in every detail.EcoPura Water Treatment Equipment & Bottling Machine pays great attention to integrity and business reputation. We strictly control the quality and production cost in the production. All these guarantee water treatment equipment to be quality-reliable and price-favorable.

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine has professional production workshops and great production technology. water treatment equipment we produce, in line with the national quality inspection standards, has reasonable structure, stable performance, good safety, and high reliability. It is also available in a wide range of types and specifications. Customers' diverse needs can be fully fulfilled.Compared with products in the industry, EcoPura Water Treatment Equipment & Bottling Machine's water treatment equipment has the outstanding advantages which are mainly reflected in the following aspects.

Company Advantages
1. Because of its ro water plant design, water treatment system is often preferred by costumers.
2. This product feature delicate workmanship. Its paint is finely done with automatic painting machine, and its parquets are all hand-made with good details.
3. The product is highly resistant to stains. Its surface has been polished to be smooth, which makes it not easy to hide dust and dirt.
4. Shenzhen EcoPura Water Equipment Co.,Ltd has a wealth of engineering experience with qualified professional and technical personnel.

Product Detail

EcoPura strict inspection water treatment system solution expert for the global market-1

Reverse Osmosis Water Plant 127,000GPD

All ECOPURA SUPER RO Systems are be equipped with a complete centralized control panel including an HMI Programmable Logic Controller featuring an integrated Full Color Graphic Touch Screen Operator Interface.
All operating conditions and process are simultaneously displayed on touch screen whilst with sensor monitoring for each working process on the panel. The operator interface is virtually menu-less, making it easy to locate and adjust all time delays and set points.
The ECOPURA Reverse Osmosis 127,000 GPD | Eco-RO20000L are the optimal Water Purification choice for Brackish or Borehole Water Treatment Projects, as it includes all the necessary treatment components to deal with the toughest water quality conditions. The ECOPURA Reverse Osmosis Water System is capable of removing salts, contaminants and impurities with a molecular size greater than 0.0001um, this system comes with capacities 20,000L/h and a maximum feed water TDS 10000ppm if some parts upgrade
We offer Standard Series Units as well as customizable to fit your water application requirement. ECOPURA provides the best in Reverse Osmosis Technology. ECOPURA custom engineer, design, fabricate and manufacture to suit the toughest Water Purification conditions around the world without compromises. In addition, we’re particularly noted for our technical services and our after sales support, and we are available to assist with your specific customized applications. The ECOPURA Reverse Osmosis (RO) systems are designed and custom built to meet our Clients requirements and specifications for reliable higher purity water and higher efficiency for a variety of manufacturing processes.

Product Detail

Standard Features

Instrumentation

Optional Features

Backwash & Regenerations Cycle

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd has built a reputation based on its years of a solid foundation in developing and manufacturing ro water plant .
2. Shenzhen EcoPura Water Equipment Co.,Ltd has a group of staff full of vitality and enthusiasm.
3. Based on the idea of water treatment system , EcoPura has always been standing at the strategic height to push forward implementation of the plans. Inquire online! best water purifier is the lifeblood and reputation of Shenzhen EcoPura Water Equipment Co.,Ltd. Inquire online!

distilled water equipment

Introduction

RO system is widely used in preparation of water for beverage industry, which features adaptable of different salt content of water, easy operation, less labor force and low running cost.

Flow Chart of Working Procedure

Raw Water	→	Raw Water Tank	→	Raw Water Pump	→	Mechanical Filter	→

Active Carbon Filter	→	Ion Exchanger	→	Precision Filter	→	High-pressure Pump	→

1-stage RO System	→	Pure Water Tank	→	Pure Water Pump	→	Final Filter	→

distilled water equipment

Composition of Water Treatment System

Pre-treatment System.

Pre-treatment system is composed of mechanical filter, active carbon filter, Ion Exchanger and precision filter. The water temperature requires 25±3⁰C.

Flocculator is used for destroying electro-neutral of colloid in water, which ensures raw water can reach to the requirement of Silt Density Index (SDI) ≤ 4. Mechanical filter can remove most of suspension, colloid and grain impurity, which can ensure initial purification of water.

If some of raw water comes from tap water, chlorine content maybe is higher. Low-pressure compound RO membrane has strict limitation to chlorine and organism, which must be ≤0.1mg/1.

Because calcium and magnesium content in raw water is very high, and RO salt-removing rate is about 97%, which may cause deposit of calcium carbonate, magnesium carbonate, bitter salt, etc. on concentrated water side. Deposit adhered on RO membrane surface and may block passage of components and causes pressure difference increase, water output decrease and salt-removing rate decrease, which influence normal running and usage span of RO. So before precision filter, Ion Exchanger is equipped to protect and avoids impurity on RO concentrated water side.

RO System

RO system is composed of high-pressure pump, RO system and chemical cleaning device.

During running, RO membrane may form some deposit and chemical cleaning device is equipped for periodical cleaning to ensure stable running of RO system. This system configures with membrane compounds and high-pressure pump.

High-pressure pump is the power source of RO system. To RO system on sound running condition, high-pressure pump equips inlet/outlet pressure switch. When inlet pressure is less than set value (water lack P≤0.05Mpa) or outlet pressure is higher than set value, pressure switch send signal to PLC programming system and high-pressure pump and RO system will stop in avoidance of destroying to RO membrane because of water pressure.

RO system pressure control and automatic cleaning are controlled by PLC. RO system can wash surface of RO membrane by low-pressure timely and periodically.

Main Equipments Description

Raw Water Pump 1 set

Model: 4-50

Brand: Nanfang Pump

Quartz sand filter 1 set

Material: SUS304

Overall dimensions: D450×H2000 (mm)

Active carbon filter 1 set

Material: SUS304

Overall dimensions: D450×H2000 (mm)

Sodium ion exchanger 1 set

Material: SUS304

Overall dimensions: D450×H2000 (mm)

Precision filter 1 set

The filter medium of the precise filter is made of micro-hole film, it is the modern advanced equipment for the filter and widely used in medicine, electrical, food industries.

Working pressure: ≤0.3Mpa

Production capacity: 4T/h

Overall dimensions: D400×H1000 (mm)

Material: SUS304

Reverse osmosis 1 set

Capacity: 2T/H, 8 sets 4040 (Hydranautics)

One stage reverse osmosis

Pump: CDLF4-16 (Nanfang)

Ultraviolet radiation sterilizer 1 set

Working pressure≤0.2 Mpa

Treatment Capacity 2T/H

Overall dimensions: 116×75×65mm

Ozone generator 1 set

Capacity: 7g

Overall dimensions: 400×320×600mm

Material: Carbon Steel

Gas-liquid mixing pump 1 set

Model: 25QY-2

Brand: Nanfang Pump

Pure water tank

Raw Water Tank

Material: SUS304

Volume: 2m³

distilled water equipment distilled water equipment distilled water equipment distilled water equipment

Any questions please feel free to contact me !

Our Services

1, the guarantee of our machines is at least two years, also we will send 3% of sales value as spare parts along with the machines free of charge, the parts will be enough for at least 3 years for the normal operation of machines.
2, we can train your engineers in our factory free of charge. It means you can send your engineers to our factory to study and training, we have rich experiences for the training, it is the good way to make sure that you can operate and maintain our machines successfully and for long term normal use.
3, we will offer you detail manual books for our machines, also we will make one Video CD to show you how to install and maintain the machines, the CD is the movie for the machines, it will be the great references for you to maintain the machines for the long time.
4,another way is that we can send our engineers to your factory to install the machines and train your engineers, we think it is the best way to help you operate and maintain the machines. We have been doing the install jobs for our overseas customers for many years. In this way you need to pay for the travel costs for our engineers, because our initial quotes don’t include the travel costs.
5, All of the electrical parts in our machines are CE or TUV approved. We can offer you UL or CUL/CSA approved parts if you need for the North American markets. The good electrical parts are the guarantee for the good quality for our machines.
