standard water treatment process 12500gpd exporter for the global market

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine always insists on the idea that service comes first. We are committed to fulfilling customers' needs by providing cost-effective services.

Company Advantages
1. Bacteria cause food to spoil. To prevent the bacteria, EcoPura water filter machine is exclusively developed with dehydrating function which is able to kill the bacteria while at the same time, retain the original flavor of the food.
2. The product is not subject to the water. Its housing is well sealed and can be wiped with clean water without affecting the internal circuitry.
3. With its reliability, the product requires little repairs and maintenance, which will greatly help save operation costs.
4. This product requires very few workers, which helps to reduce labor costs. This will ultimately help manufacturers gain a competitive advantage.

Product Detail

Seawater Reverse Osmosis Systems SWRO

From water-makers to industrial sized Seawater Purification, we offer a full range of systems. Our units are manufactured to eliminate a large amount of salts and other minerals from seawater using RO. Our equipment does the filtration by employing a high-pressure pump to salty water forcing it through semi-porous membranes denying salts and other organics from flowing through. The membranes are only tasked to remove dissolved solids while dividing the feed water into purified water and rejected concentrated salts. The salts and other organics are thrown into the brine stream then flushed into a drain. At the end we have purified water that has 99% less dissolved salts. These sea water RO systems have the power to purify extremely high TDS water. Seawater RO systems are usable anywhere from yachts to municipalities.

EcoPura standard water treatment process exporter for the global market-1

EcoPura standard water treatment process exporter for the global market-2

Industrial Seawater Reverse Osmosis desalination system

For continuous or heavy-duty service in marine applications on and off shore, ECOPURA manufactures a full line of designed seawater desalination systems

Seawater Reverse Osmosis

Seawater Reverse Osmosis (SWRO) is a reverse osmosis desalination membrane
process with typical single pass SWRO system consists of the following components:
Intake: well or open water
Pre-treatment: Filtration and chemical dosing
High-pressure pump: to achieve the needed pressure
Membrane assembly: to perform the desalination process
pH adjustment: to adjust the alkalinity or acid level
Disinfection: to prevent any bacterial or organic growth

EcoPura standard water treatment process exporter for the global market-3

EcoPura standard water treatment process exporter for the global market-4

Customizable RO System Capacity

Our Industrial SWRO Series is available with capacities ranging from 8,000 GPD to 660,000 GPD and a maximum feed water TDS of 45,000 ppm. We can provide standard SWRO Series units as well as customizable to fit you water application needs. ECOPURA Sea Water Reverse Osmosis Systems are capable of removing salts as well as other impurities such as bacteria, sugars, proteins, dyes and constituents that have a molecular weight greater than 150-250 Dalton. ECOPURA supplies a full line of standard and customizable Sea Water Reverse Osmosis systems, all of which are engineered using advanced 3D computer modeling and process design software for accurate and customized solutions.

Product Specification

Operation Specifications

Max. feed water temperature: 42°C

Equipment upgrade for TDS up to 50,000 ppm

H2S, turbidity and organics must be removed

Feed water TDS: 10,000-42,000 ppm

Operating pressure: 700 to 1,000 ps

pH tolerance range: 3-11

Feed water pressure: 40 to 80 psi

Antiscalant dosing is required

Max. Iron content: 0.05 ppm

Model	Capacity		Qty of 8040 membranes
Model	GPD	M3/D	2
SWRO8000	8000	30	3
SWRO12000	12000	45	4
SWRO16000	16000	60	6
SWRO24000	24000	90	8
SWRO32000	32000	120	12
SWRO48000	48000	182	16
SWRO64000	64000	242	18
SWRO72000	72000	273	24
SWRO96000	96000	363	28
SWRO112000	112000	424	34
SWRO136000	136000	515	42
SWRO168000	168000	636	49

Operation Specifications

Available Options

Powder coated steel frame

Heavy duty 5 micron cartridge prefilter

Sea water resistant SS pump

Microprocessor/PLC based control panel & VFD

Glycerin-filled 316 SS prefilter pressure gauges

Product & reject flow meters

TFC spiral wound membranes

FRP membrane housings

380V/3Ph/50Hz power supply

Low & high pressure switches

Permeate TDS monitor

Stainless steel high pressure piping

Stainless steel throttling valve for reject stream

Automatic feed shut off valve

Energy recovery on 64K GPD and larger

Booster pump

380-415V/3Ph/50Hz power supply

Product tank level switch

pH controller with sensor

ORP controller with sensor

Hour meter

Cleaning skid

50 micron bag filter for open intake

Carbon prefilter

Multimedia prefilter

UV sterilizer

Custom designed units

Export crating

Chemical dosing units

The ideal applications for an Industrial Sea Water RO system include

Oil Tankers

Island-Based Businesses

Villages & Cities

Cargo Ships

Coastal Developments

Hotels & Resorts

Seaside Work Sites

Work Boats

Fish Processing Plants

Seaside Villas

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is one of the preferred Chinese suppliers of water filter machine for customers worldwide. We are known for producing quality products.
2. water treatment process is produced by adopting traditional and modern technology to ensure first-class quality.
3. Our company is dedicated to three objectives: providing high-quality products at competitive prices with the quickest turn around time in the world. We are committed - longstanding and meaningful relationships are the lifeblood of our business. We’re in it for the long run and will always strive to remain the one and only choice for reliable manufacturers. We are cultivating a working environment that gives our team room and freedom to be themselves and work in a way that strengthens and adds value to our relationships.

home softeners magnetic for 6000 gauss drinking water treatment process

Product Description

   Analysis: charged particles through the strong magnetic field will produce Lorentz force and swiftly move to the side, positive ions and negative ions will move in the opposite direction. Under high speed and strong magnetic field, charged particles shot out like a bullet. This will cut and impact the water molecules. Then macro molecules will turn into small molecules, and after hitting, there will be a lot of oxygen with two electrons, called negative oxygen ions, also known as negative ions. Water itself is also weak electrolyte,can be affected by the Lorentz force, so the state of the water after magnetization can be maintained for a long time.

1. softened water is activated

Small molecules of water: particularly easy to absorb, add water to human body, attract people to love drinking water

Antibacterial water: improve water environment and negative ions attached to the bacteria will stop the bacteria to absorb nutrition and reproduction

2. There are drinkable negative ions in softened water

Use the most simple way of drinking to add anion to human body, keep healthy

softened water in daily life

1. Salted salt test: put some salt on white paper, and then put the white paper on the cup with softened water, softened water released energy can change the salty taste after 10 minutes

2. Remove the odor test: pour the high-energy softened water into the bathroom or in the refrigerator, half an hour later it can remove the smell in the toilet or refrigerator; put high-energy softened water into the fish tank, 20 minutes later the fish small can be removed

3. Cleaning oil test:put rags in the high-energy softened water for several minutes, use the same amount of water with the detergent, softened water cleans better

4. PH test: softened water is found increasing water PH by 0.2-0.8

5. Solubility test: respectively, in the same amount of tap water and softened water, keep on putting sugar, until there is left sugar in the bottom of the cup that can not be d i ssolved, softened water dissolves more sugar than tap water

6. Descale test: start using the softened water for the kettle with old scale, in a short period of time (within half a month) , will find the original scale gradually disappear

Scale formation principle:

Calcium ions , Magnesium ions + Carbon Dioxide in water = Calcium Carbonate, Magnesium Carbonate (Scale)

Descaling principle:

Calcium ion, magnesium ion + carbon dioxide in water (via magnetic field) = calcium bicarbonate, magnesium bicarbonate (easily dissolved)

Product Pictures

Company Information

Vigorrain Technology Co.,Ltd is specialized in water and air treatment products manufacturing and wholesaling with rich experiences for 17 years. Products have been applied for patents and sold overseas and dom e stically with very good feedback and reputations. Vigorrain offers clients not only best products with superior performance, but also detailed product data sheet and manual for customers' projects. Our engineer team & sales team are always well prepared to offer in depth technical support and sales service on all aspects of installation and use.

Shipment

The normal package is strong foam and carton box(Size upon models).Normal orders are packed by our company's packings, customers' customized packing is available too.

For sea shipping it will cost 5-40 days upon destination; By air usually 5-8 days; By express 5-8 days.

Usually we will confirm with customers about the shipping ways( for shipping days and freight requirement). Customers can inform us about specially needed shpping marks and so on.

Payment

Payments can be made by L/C, D/A,D/P,T/T,Western Union, Money Gram, Trade Assurance, and Paypal

Contact

Contacts :	Corrine Yeh
Tel :	+86 755 8967 7921
Phone :	+86 187 1879 9415
Email :	vigorraintech at 163.com
Homepage:	https://vigorrain.en.alibaba.com

FAQ

Q: Do you accept sample order?

A: Sample order is acceptable. Sample can be sent within 1~3 days after payment confirmed.

Q: What are your payment terms?

A: Paypal, Western union, T/T, etc. 30% as deposit, balance before shipping. 100% in advance for sample order.

Q: What is your delivery term?

A: EXW/FOB/CIF; By express/By sea/By air; Deliver after payment confirmed.

Q: How long is your warranty?

A: Depends on different products. We will try the best to provide best after-sale service.

Exibition&Customers

w******g

Through our innovative use of the latest technology, the manufacturing process of the EcoPura water filter machine is optimized.

q******f

EcoPura water treatment process is made by adopting international advanced technologies.

d******m

EcoPura water filter machine benefits from a higher level of attention of detail.

d******p

High technical assurance and first-class quality can be seen on water filter machine.

i******y

Thanks to the low cost of raw materials and the high efficiency of streamlined production, water treatment process products have the advantage of high gross profit margin.

e******s

water filter machine Made of high-quality raw materials, it has good stain resistance, mildew and algae resistance, can keep the wall smooth and clean for a long time, and effectively inhibits the growth of mold and algae.
