Product Details

EcoPura Water Treatment Equipment & Bottling Machine adheres to the principle of 'details determine success or failure' and pays great attention to the details of bottle filling machine.EcoPura Water Treatment Equipment & Bottling Machine insists on the use of high-quality materials and advanced technology to manufacture bottle filling machine. Besides, we strictly monitor and control the quality and cost in each production process. All this guarantees the product to have high quality and favorable price.

Application Scope

water treatment equipment can be applied to multiple scenes. The following are the application examples for you.EcoPura Water Treatment Equipment & Bottling Machine always gives priority to customers and services. With a great focus on customers, we strive to meet their needs and provide optimal solutions.

Company Advantages
1. juice filling machine price design can provide juice filling equipment with a long service life and extremely high performance.
2. The product features enough tensile. The materials used have been tested to stand up the working force applied to it.
3. It has widely found its applications in the industry because of these fine properties.
4. The product has wide application foreground and potential in its field.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura standard juice filling equipment looking for buyer for trader-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura standard juice filling equipment looking for buyer for trader-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura standard juice filling equipment looking for buyer for trader-3

EcoPura standard juice filling equipment looking for buyer for trader-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura standard juice filling equipment looking for buyer for trader-5

EcoPura standard juice filling equipment looking for buyer for trader-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd has become a backbone enterprise after years of development in the juice filling equipment industry.
2. EcoPura is the main force in designing, developing , research and development, manufacturing and sales of juice bottling machine .
3. Shenzhen EcoPura Water Equipment Co.,Ltd hopes that our juice filling machine will benefit every customer. Check now! Shenzhen EcoPura Water Equipment Co.,Ltd's juice filling equipment is a symbol of strong production capabilities. Check now! EcoPura will increase its international fluency in the juice filling equipment field. Check now!

s******i

EcoPura juice filling machine price is under the real-time control of the R&D team. The team will carry out a routine sampling and analysis of the raw materials so as to acquire information necessary for the economic appraisal of ores and concentrates.

o******c

EcoPura juice filling machine is produced under advanced equipment. It will be processed by fastness to washing tester, steamer and washer, as well as vacuum cleaning equipment designed for textile.

n******v

EcoPura juice filling machine is under constant control in terms of health, safety, and environmental protection standards, as evidenced by the CE certificate issued.

r******m

The quality control of EcoPura juice filling machine is conducted rigorously. It is tested in terms of its air circulation, surface treatment, as well as the most important part, thermal dissipation performance.

v******h

All EcoPura juice filling equipment are manufactured in compliance with rubber and plastic industry standards and are tested for quality conformance in the laboratory.

s******q

The product features stable performance. The proportions of the various raw materials are carefully mixed together to achieve consistent properties.
