standard juice bottling machine 4in1 looking for buyer for upgrade industries

Company Advantages
1. Before delivery, EcoPura bottling juice equipment has to undergo a wide range of tests. It is strictly tested in terms of the strength of its materials, statics&dynamics performance, resistance to vibrations&fatigue, etc. The product is widely used for commercial applications
2. The product has gained much acceptance and popularity in the field. The use of this product helps in increasing the production of drinks
3. Now the performance of this product is improved at every turn by powerful technologies. The product features excellent purification technology
4. The international quality certifications shows the good quality of this product. The product can enhance the speed, accuracy, and efficiency of workers
5. The quality of this product is tested for many times to meet the requirements of quality standards. It has a robust design, supported by an aluminum plate

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura standard juice bottling machine looking for buyer for upgrade industries-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura standard juice bottling machine looking for buyer for upgrade industries-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura standard juice bottling machine looking for buyer for upgrade industries-3

EcoPura standard juice bottling machine looking for buyer for upgrade industries-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura standard juice bottling machine looking for buyer for upgrade industries-5

EcoPura standard juice bottling machine looking for buyer for upgrade industries-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd has a number of skilled workers and a complete product line.
2. Our mission is to make customers' business even more successful. We respond to their individual requirements with innovative product concepts. Our solutions will inspire every customer.

p******i

The bottling juice equipment manufactured by us with advanced design concepts not only strives for excellence in workmanship, scientific and reasonable design, but also has stable performance and durability, which can meet customers' needs for high-quality products.

g******e

Shenzhen EcoPura Water Equipment Co.,Ltd Not only are the raw materials used high-quality, but also the production equipment and technology are advanced, thus ensuring that the produced juice bottling machine is of high quality and excellent quality.

k******r

juice bottling machine of Shenzhen EcoPura Water Equipment Co.,Ltd is made of selected high-quality materials, and the overall design is scientific and reasonable, the finished product is of good quality, and has a high market value.

j******c

Shenzhen EcoPura Water Equipment Co.,Ltd Strict checks are carried out during the supply of raw materials and the process of product production to ensure that the bottling juice equipment produced are of reliable quality, and the appearance, function, and quality of the product are carefully inspected before the goods are sent out to ensure that the products sold The products are consistent with the product descriptions displayed by us.

f******e

As a professional and responsible juice bottling machine manufacturer, we always put product quality first, insist on using high-quality raw materials and advanced production technology to manufacture juice bottling machine, and strictly control every production process to ensure that all juice bottling machine are qualified Products, to bring reliable quality assurance to customers.

j******u

State-of-art production equipment and test equipment ensure the quality of this product. Thanks to its tissue-friendly design, the product can decrease postoperative pain, ecchymoses, and edema
