standard juice bottling machine 4in1 looking for buyer for distribution

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine insists on the principle of 'integrity, professionalism, responsibility, gratitude' and strives to provide professional and quality services for customers.

Application Scope

bottle filling machine can be applied to multiple scenes. The following are the application examples for you.Since the establishment, EcoPura Water Treatment Equipment & Bottling Machine has always been focusing on the R&D and production of water treatment equipment. With great production capability, we can provide customers with personalized solutions according to their needs.

Company Advantages
1. The design concept: the design concept of EcoPura juice filling machine price is positioned high in our company. The design, in addition to the support of a team of talented designers, is also based on the market survey.
2. The stipulate strict quality inspection through the whole process guarantees the product is of the quality that meets the industry standard.
3. The product makes people's jobs much easier and it is labor-saving. People can use it to increase the overall efficiency and cut labor costs.

Product Detail

ECOPURA 3-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura standard juice bottling machine looking for buyer for distribution-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
DHSG16-16-12-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	3000-3500bph	1.8kw	SIEMENS
DHSG24-24-16-6		4000-5000bph	2.2kw
DHSG24-24-18-8		5000-6000bph	2.2kw
DHSG24-24-8		8000-9000bph	3.0kw
DHSG32-32-32-12		10000-12000bph	5.5kw
DHSG38-38-38-14		12000-15000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

EcoPura standard juice bottling machine looking for buyer for distribution-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination. The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura standard juice bottling machine looking for buyer for distribution-3

EcoPura standard juice bottling machine looking for buyer for distribution-4

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene.Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish. As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

EcoPura standard juice bottling machine looking for buyer for distribution-5

EcoPura standard juice bottling machine looking for buyer for distribution-6

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is well-known for abundant experience in developing and manufacturing juice filling machine price . We have evolved into a large scale company.
2. Shenzhen EcoPura Water Equipment Co.,Ltd has taken macro measures to improve the R&D environment.
3. Shenzhen EcoPura Water Equipment Co.,Ltd keeps the business value of juice bottle filling machine . Get price! Sustainable development for Shenzhen EcoPura Water Equipment Co.,Ltd is what we are striving for. Get price!
