standard juice bottling machine filling international market for trader

Company Advantages
1. The stylish EcoPura tea filling machine is designed by our design experts. Made of stainless steel materials, the product has a smooth surface to resist dust and dirt
2. With the above excellent characteristics, the product has good competitiveness and good development prospects. With a compact structure, the product can operate stably
3. There is sufficient strength inside this product. Force analysis is performed prior to manufacture to find the forces acting on each element. And the best-suited materials are chosen to withstand these forces. The product is equipped with a high-efficiency operation system
4. This product has good strength. Any suddenly applied or impact load which may cause failure has been taken into consideration in the design phase. Adopting an intelligent circuit design, the product has a self-check function
5. This product meets the requirements of safe use. Safety testing has been performed based on mechanical design/performance, the intent of the product, the conditions of use and more. The product can ensure a high filtration rate

Product Detail

ECOPURA 4-in-1 PET 0.3L-1.5L RHSG-series Hot-fill monobloc equipped with electronic filler nozzles designated for filling hot beverages such as Juice ,tea,pulp beverages or those liquid mixed particles

EcoPura standard juice bottling machine international market for trader-1

Product Specification

Model	Bottle Spec	Capacity Cal@500ML	Power	PLC & HMI
RHSG24-24-16-6	0.33L-1.5L Height:150-330mm Dia: 50-115mm	5000-6000bph	2.2kw	SIEMENS
RHSG24-24-18-8		7000-8000bph	2.2kw
RHSG24-24-24-8		10000-12000bph	2.0kw
RHSG32-32-32-12		15000-18000bph	5.5kw
RHSG38-38-38-14		18000-20000bph	7.5kw
EcoPura’s Filling machines are include but not-limited to above list,more info pls contact us.

Why 4-in-1 ?
Twin bottle rinsing station include chemical water rinsing and Ozonated water rinsing ensuring the performance with strict hygiene standard

EcoPura standard juice bottling machine international market for trader-2

High quality & Strict Hygiene

Production of top-quality beverages requires conditions of strict hygiene, All parts that comes into contact with the beverage are manufactured in Stainless steel 304 or 316
Contactless filling
SIEMENS PLC & Touch Screen control with Integrated and separate electro-pneumatic components

Chemical Washing Part

The machine applies unique overturning bottle clamp, Made of Stainless Steel 304 or 316 hygienic and durable. Which grips bottle at neck position, avoiding bottle mouth contamination .The high efficiency atomizing spray nozzle installed on bottle clamp is capable of cleaning any part of bottle inner wall, and saves rinsing water.

EcoPura standard juice bottling machine international market for trader-3

EcoPura standard juice bottling machine international market for trader-4

Ozonated Water Washing Part

Filling Part

Stainless Steel 304 or 316 Filling valves are designed and manufactured featuring high filling accuracy and high filling speed whilst contactless filling ensures high level of hygiene. Neck-handling grippers position the PET container beneath the filling valve. Once the container has been centred, the filling process starts: Thereby, the Filling valve is opened and the product flows into the bottle with infinitely variable speed. Once the required fill volume has been reached, the flow meter provides a signal to the filling valve. The valve is now closed and the filling process completed. Dripping of the filling valve is prevented by a sieve in the product discharge. Microbiological safety by filling in a multi-chamber mode and separate return gas channel Precise determination of fill quantity via inductive flow meter Recirculation channel for heat retention of the product Perfect flow characteristics through two filling speeds Cleaning in a closed system using automatically positioned CIP cups

EcoPura standard juice bottling machine international market for trader-5

EcoPura standard juice bottling machine international market for trader-6

Capping Part

The capper is most precise part ensuring the machine to run credibility and product quality.The capping head applies the cap. The cap is pressed onto the bottle by means of spring pressure. At the same time it is screwed onto the thread of the bottle neck finish.As soon as the rotation is ended and the required tightening torque is applied to the cap, a hysteresis clutch ends the capping process. All main parts made of stainless steel AISI304 Pick station with adjustable height Torque and spring force of the capping head are adjustable Flushable cap retainer Motorised height adjustment of the capper top part with bottle selection feature

Caps online Sterilization

ECOPURA dedicated in every process details to control the hygiene such as for the caps sterilizing to ensure the maximum hygiene for your all kinds beverages. Caps online sterilizer made of stainless steel 316L with built in spraying device for high pressure Ozonated pure water sterilizing

EcoPura standard juice bottling machine international market for trader-7

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd is a supplier of juice bottling machine with trusted manufacturing abilities. We have years of combined experience in the field.
2. Shenzhen EcoPura Water Equipment Co.,Ltd enjoys strong technical strength with excellent equipment, exquisite techniques and normative management.
3. We are always in full preparation serve our customers well for our juice filling machine . Contact us!
