automatic mineral water bottle filling machine machine manufacturer for commercial production

Product Comparison

EcoPura Water Treatment Equipment & Bottling Machine pays great attention to integrity and business reputation. We strictly control the quality and production cost in the production. All these guarantee water treatment equipment to be quality-reliable and price-favorable.water treatment equipment has the following differentiated advantages compared with other products in the same category.

Enterprise Strength

EcoPura Water Treatment Equipment & Bottling Machine adopts the strategy of the two-way interaction between enterprise and consumer. We gather timely feedback from dynamic information in the market, which enables us to provide quality services.

Company Advantages
1. The design of EcoPura mineral water bottle filling machine involves several factors. These factors include part tolerances, size limitations, materials selection, mechanical analysis, function realization, etc.
2. The mineral water bottle filling machine shows great performance in water filling machine for sale and filling system .
3. Shenzhen EcoPura Water Equipment Co.,Ltd will regulate its market management in the coming days.

Product Detail

ECOPURA 5gallon bottle washing filling capping machine HSG2000 with capacity 2000bph
A real Hygiene filling solution for your recycling use 5Gallon bottled water business with SIEMENS PLC Control and touch Screen control. All parts that come to contact with water are manufactured in Stainless steel 304 or 316L ,Equipped S.S304 Chemical tank for multistage rinsing

EcoPura machine mineral water bottle filling machine manufacturer for commercial production-1

EcoPura machine mineral water bottle filling machine manufacturer for commercial production-2

EcoPura machine mineral water bottle filling machine manufacturer for commercial production-3

EcoPura machine mineral water bottle filling machine manufacturer for commercial production-4

EcoPura machine mineral water bottle filling machine manufacturer for commercial production-5

EcoPura machine mineral water bottle filling machine manufacturer for commercial production-6

Bottles Sterilizing & Washing

Exclude the brusher pre-washing process for cleaning bottles inside & outside part, the pre-washed 5gallon bottles feed into the 3-in-1 washing filling capping unit which Designed Multistage high-pressure inner washing Process include Hot Alkaline washing, disinfection water washing, Dripping ,Ozonated pure water cleaning for ensuring the recycled bottles 100% clean & health, the washing system is controlled by pumping though cleaning tank and the ejecting nozzles on the bottle carrier to spraying the inner wall of the bottles by high pressure water, after finishing the washing process, the bottles will discharge though reverse turn-over mechanize and transported to the filling Part for full filling as designated volume and finally capping, discharge out the 3-in-1 by conveyor to next step

Caps Loading & washing

The Caps elevator doses the caps into the caps unscrambler then delivery through caps chute to enter into caps washing tunnel, finished clean caps feed following the chute transferring to capping position on capping machine

Design for online 5Gallon caps cleaning & Sterilizing by multistage washing process -detergent washing & purified water washing

EcoPura machine mineral water bottle filling machine manufacturer for commercial production-7

EcoPura machine mineral water bottle filling machine manufacturer for commercial production-8

Rotary Filling & Capping

Clean bottles are discharged out of the rinse by conveyor to feed the filler. After entering the filler, bottles are retained by bottom supporting plates, which are actuated by bottle supporting mechanism to raise them to engage with filling valves. Filling valves are opened by bottle presence signals. After finishing filling, valves are closed by valve closing mechanism to further stop venting to complete the filling process.

Product Solution

A turnkey solution for 5Gallon bottling line

♦ 1.Automatic bottle decapper
♦ 2.Automatic inside & outside brusher washer
♦ 3.Automatic bottle feeder -Multistage high-pressure washing unit
♦ 4.Linear or Rotary filler & capper
♦ 5.Automatic Capsules Labeling shrinking
♦ 6.Light Inspection
♦ 7.Thin film (bag) Packing
♦ 8.Palletizer

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd stands out among other manufacturers in the mineral water bottle filling machine industry.
2. We expect no complaints of filling equipment from our customers.
3. We embrace sustainability all the time. We invest in automation technologies and continuously work to reduce our carbon footprint across the value chain. We bear social responsibility. We place the highest demands on our activities in our sphere of influence and in all distribution chains. We keep up with the rapid changes in the modern age, maintaining the core values and strive to provide the best service to our customers. Welcome to visit our factory!
