automatic mineral water bottle filling machine machine factory for industrial production

Product Details

With a focus on product quality, EcoPura Water Treatment Equipment & Bottling Machine pursues perfection in every detail.EcoPura Water Treatment Equipment & Bottling Machine insists on the use of high-quality materials and advanced technology to manufacture water treatment equipment. Besides, we strictly monitor and control the quality and cost in each production process. All this guarantees the product to have high quality and favorable price.

Company Advantages
1. After the production of EcoPura mineral water bottle filling machine , it is required to go through the water test, inflatable test, air leakage test, etc, so as to guarantee its reliability.
2. This product features a sturdy and hard structure. This robust machine structure enables it to withstand heavy-duty and rigorous operating conditions.
3. Our ongoing commitment to research and development has enabled us to successfully and independently introduce a wide variety of mineral water bottle filling machine .
4. All mineral water bottle filling machine will be well packed in pallets and will be well protected for long-distance transportation.

Product Detail

ECOPURA 5gallon bottle washing filling capping machine HSG600 with capacity 600bph.
A real Hygiene filling solution for your recycling use 5Gallon bottled water business with SIEMENS PLC Control and touch Screen control. All parts that come to contact with water are manufactured in Stainless steel 304 or 316L ,Equipped S.S304 Chemical tank for multistage rinsing

EcoPura machine mineral water bottle filling machine factory for industrial production-1

EcoPura machine mineral water bottle filling machine factory for industrial production-2

Bottles Sterilizing & Washing

Exclude the brusher pre-washing process for cleaning bottles inside & outside part, the pre-washed 5gallon bottles feed into the 3-in-1 washing filling capping unit which Designed Multistage high-pressure inner washing Process include Hot Alkaline washing, disinfection water washing, Dripping ,Ozonated pure water cleaning for ensuring the recycled bottles 100% clean & health, the washing system is controlled by pumping though cleaning tank and the ejecting nozzles on the bottle carrier to spraying the inner wall of the bottles by high pressure water, after finishing the washing process, the bottles will discharge though reverse turn-over mechanize and transported to the filling Part for full filling as designated volume and finally capping, discharge out the 3-in-1 by conveyor to next step

Caps Loading & washing

The Caps elevator doses the caps into the caps unscrambler then delivery through caps chute to enter into caps washing tunnel, finished clean caps feed following the chute transferring to capping position on capping machine .Design for online 5Gallon caps cleaning & Sterilizing by multistage washing process -detergent washing & purified water washing,

EcoPura machine mineral water bottle filling machine factory for industrial production-3

EcoPura machine mineral water bottle filling machine factory for industrial production-4

Rotary Filling & Capping

Clean bottles are discharged out of the rinse by conveyor to feed the filler. After entering the filler, bottles are retained by bottom supporting plates, which are actuated by bottle supporting mechanism to raise them to engage with filling valves. Filling valves are opened by bottle presence signals. After finishing filling, valves are closed by valve closing mechanism to further stop venting to complete the filling process.

Product Solution

A turnkey solution for 5Gallon bottling line

♦ 1.Automatic bottle decapper
♦ 2.Automatic inside & outside brusher washer
♦ 3.Automatic bottle feeder -Multistage high-pressure washing unit
♦ 4.Linear or Rotary filler & capper
♦ 5.Automatic Capsules Labeling shrinking
♦ 6.Light Inspection
♦ 7.Thin film (bag) Packing
♦ 8.Palletizer

Company Features
1. Shenzhen EcoPura Water Equipment Co.,Ltd has a number of modern production lines to produce high quality mineral water bottle filling machine .
2. Our professional equipment allows us to fabricate such water filling machine for sale.
3. Environmental protection has been a long tradition of our company. We using technological advances and innovative solutions to minimize the negative impact of our operations on the environment. We are a firm with a strong corporate philosophy. This philosophy enables us to focus on one thing: to manufacture the best products with high quality. Get more info!

e******m

Shenzhen EcoPura Water Equipment Co.,Ltd has a modern factory building, and introduces advanced water filling machine for sale production equipment, and water filling machine for sale after the production is completed, it will be tested by the relevant national departments to meet the national quality standards, ensuring that it not only has high output, but also stable performance and high quality .

y******g

Shenzhen EcoPura Water Equipment Co.,Ltd After years of careful management, a set of scientific and rigorous production process has been established, and the quality is strictly controlled in all aspects of product design, production, quality inspection, and delivery. The mineral water bottle filling machine produced is fine in workmanship and high in quality , Strong practicability.

n******d

water filling machine for sale The workmanship is fine, the materials are exquisite, the design is scientific, the structure is reasonable, and before leaving the factory, there will be special quality inspection personnel to test, so the quality is guaranteed.

f******e

We pay great attention to product quality, adhere to the introduction of scientific production concepts, adopt professional production equipment and use advanced production technology to manufacturewater filling machine for sale, and have established a complete set of quality inspection procedures to strictly test each batch of products leaving the factory to ensure that all Products are in line with national quality inspection standards.

v******p

mineral water bottle filling machine Carefully designed by professional designers, the design is scientific and reasonable, and selected high-quality raw materials are processed with advanced technology to make it of excellent quality and more durable.

i******o

This product is able to achieve maximum light output in a matter of seconds. being arranged in an orderly manner, its bulb can work simultaneously and provide full brightness in one second. It can be Open, Closed and Semi-open
